IQ 8 Residual Image RAP, IQ 9 Uneven Density RAP
Reissue
Image Quality
YN
The problem is in the Fuser. Disassembly the fuser and carefully inspect the follow-
ing parts for damage or toner buildup.
• Pressure Roll (PL
8.
3)
• Heat Rolls (PL 8.3)
• Web CRU (Machine Cons
umables)
Go to the IQ 40
2nd BTR HVPS RAP. If the 2nd BTR Power Supply is good, inspect/
replace the 2nd BTR (PL 9.2).
The problem is in the Xerographic Module, the 1st B
TR, or the IBT Belt. Complete the steps
below until the problem is resolved
• Check the IQ 41 1st B
TR HVPS RAP
• Replace the IBT Belt (PL 7.5)
• Clean/replace the IBT Cleaning Blade (PL 7.
8)
• Replace the Drum CRU (Machine Cons
umables)
IQ 9 Uneven Density RAP
Uneven Density RAP. This RAP is used when the IOT output image shows uneven density in
the inboard to outboard direction.
Initial Actions
• Ensure that all HFSI items that are near or over threshold have been replaced.
• Ensure that IBT is positioned correctly in relation to the Copy/Print Cartridge (Xero Drum).
• Check the Plate (PL 7.6) t
hat supports the outboard end of the IBT Backup Roll for dam-
age.
Procedure
Place the Color Test Pattern on the platen and make a print in Black, Yellow, Magenta and
Cyan. The defect is present in all four colors.
YN
Replace the developer material for the problem color.
NOTE: After replacing developer material, go to IQ47 ATC Sensor RAP, Appendix
1.
ATC
set-up procedure.
If the problem is still present, replace the Developer Housing f
or the problem color (PL
6.6).
Run ADJ 9.1.1
Max Setup. The Setup runs successfully.
YN
Go to the RAP for the Fault Code indicated to troubleshoot the problem.
Xerographic Hard Stop Procedure
1. Remove the Paper Handling Module Cover.
2. Make sure that the IBT Handle is up.
3. Cheat the Front Door Interlock.
4. Use the Test Pattern that displays the fault.
5. Press Start.
6. Watch the Registration Drive Gear (Figur
e 1).
7. When the gear starts to rotate, remove the interlock cheater.
8. Extend the Paper Handling Drawer.
9. Remove the two screws that secure the IBT Front Frame and turn IBT handle down.
10. Extend the IBT Drawer to the service position.
Observe the Image on the IBT. The defect is present on the IBT.
YN
Go to the IQ 40 2nd BTR HVPS RAP.
If the 2nd BTR Power Supply is good, replace the
2nd BTR (PL 7.9). If the problem continues, replace the IBT Belt (PL 7.5).
The problem is in the Xerographic Module, the 1st BTR, or the ROS. Complete the steps below
until
the problem is resolved
• Check the photoreceptor, the corotron wire, and the corotron grid for defects or damage. If
any component is quest
ionable, replace the Drum CRU Machine Consumables.
• Go to the IQ 41 1st
BTR HVPS RAP. If the 1st BTR Power Supply is good, replace the 1st
BTR (PL 7.6).
A
