1/05
2-200
DocuColor 12/DCCS50
11-190 Paper Remains on V-Tra In Sensor RAP, 11-
Reissue
Status Indicator RAPs
11-190 Paper Remains on V-Tra In Sensor RAP
The Control Logic detected that paper remained on the V-Tra In Sensor at power on.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-190 P
aper
Remains on V-Tra In Sensor RAP to troubleshoot this Fault Code.
NOTE: Ensure that Sorter S-1 Tag is installed.
Initial Actions
• Refer to BSD11.4 and BSD 11.8 for the following procedure.
• Ensure that no paper is blocking the V-Tra In sensor and
the sensor actuator moves freely.
• Check for any obstructions in the paper path.
• Ensure that P/J562 on the
Mail Box Control PWB, and P/J567 on the V-Tra In Sensor
are connected before beginning this RAP.
Procedure
Enter dC330 011-142 Vertical Transport In Sensor. Press Start. The display is L.
YN
Go to Fl
ag 1 on BS
D 11.4 and check the harness for a short circuit. If the harness is good,
replace the V-Tra In Sensor (PL 13.9).If the problem continues, replace the Mail Box Con-
trol PWB (P
L 13.10
).
More than +4.3 VDC is measured between P/J562-
8 and GND on the Mail Box Control
PWB.
YN
Replace the V-Tra In Sensor (PL 13.
9).
Check t
he V-Tra In Sensor for intermittent operat
ion. If the sensor is good, Replace the Mail
Box Control PWB (PL 13.10).
11-191 Paper Remains at Mail Box Vertical Sensor / 1 Bin
Sensor RAP
The Control Logic detected that paper remained on the Mail Box Vertical Sensor at power on.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-191 P
aper
Remains at Mailbox Vertical Sensor / 1 Bin Sensor RAP to troubleshoot this Fault Code.
NOTE: Ensure that Sorter S-1 Tag is installed.
Initial Actions
• Refer to BSD11.5 for the following procedure.
• Ensure that no paper or foreign object is blocking the Mail B
ox Vertical sensor.
• Ensure that the Mail Box Vertical sensor and t
he Vertical LED are clean.
• Ensure that P/J551 on the M
ail Box Control PWB, and P/J818 and P/J819 on the Mail
Box Vertical Sensor are connected before beginning this RAP.
Procedure
Enter dC330 011-115 Mailbox Vertical Sensor. Press Start. The display is L.
YN
+5 VDC is measured between P/
J551-3 and
P/J551-5 on the Mail Box Control PWB
YN
CR1 on the Mail Box Control PWB is on.
YN
Go to the +5 VDC wirenet and troubleshoot the wires between P/
J569-1 and
P/J44-6 on the Distribution PWB.
Replace the Mail Box Control PWB (PL 13.10).
Go to
Flag 1, Flag 2, and
Flag 3 on BSD 11.5 and check the harness for an open circuit. If
the harness is good, replace the Mail Box Vertical Sensor (PL 13.9). If the problem contin-
ues, replace the Mail Box Control PWB (P
L 13.10
).
Less than +0.5 VDC is measured between P/J551-4 an
d GND on the Mail Box Control
PWB.
YN
Replace the Mail Box Vertical Sensor (PL 13.
9).
Check t
he Mail Box Vertical Sensor for intermittent
operation. If the sensor is good, Replace
the Mail Box Control PWB (PL 13.10).
