1/05
2-80
DocuColor 12/DCCS50
Reissue
Status Indicator RAPs
7-600 Tray 5 Adjustment Side Guide out of specified Range
RAP
The machine detected that Tray 5 Side Guide was outside the specified range.
Initial Actions
• Refer to BSD 7.4 for the following procedure.
• Check for obstructions in the paper path.
• Go to the Control Panel, ensure that Tray 5 Tray P
aper Size icon is set to the correct paper
size that is loaded in Tray 5.
• Ensure that the NVM location for the Market is the correct country code, 752-001 = 2
Procedure
The paper size being utilized for this procedure matches the paper size selected on the
Touch Screen.
YN
Voltage is measured at P
/J146
-B15 on the IOT PWB and GND on the Tray 5 Size
Sensor.
YN
+5 VDC between J703B-
7 on
the Tray 5 Paper Size Sensor and GND.
YN
Go to the +
5
VDC Power (IOT LVPS) RAP.
Go to Flag 1 and Flag 2 on BS
D 7.4 and check the harness for an open circuit or
short to GND. If the harness is OK, replace the Tray 5 Size Sensor (PL 2.13).
Go to Flag 2 and F
lag 3 on BSD 7.4 and check the harnesses for an open circuit or short
to GND. If the harness is OK, replace the IOT Drive PWB (PL 9.2).
Check/Replace the following parts in the order listed unt
il the problem is resolved. Replace any
parts that are worn, binding, or missing.
• Spring (PL 2.5)
• Link (PL 2.5)
• Tray 5 Assembly (PL
2.
9)
