1/05
8d-24
DocuColor 12/DCCS50
11-302 Decurler Door Interlock Open RAP, 11-303
Reissue
Finisher/Sorter
11-302 Decurler Door Interlock Open RAP
Decurler Door Interlock Open Failure. This status code is declared when the Decurler Front
Cover is open.
Initial Actions
• Refer to BSD12.1 for the following procedure.
• Ensure that P/J1033 on th
e Finisher PWB, and P/J1018 on the Decurler Door Interlock
Switch are connected before beginning this RAP.
• Check the Front Cover for proper alignment.
• Verify that the Front Cover closes properly.
Procedure
Enter dC330 012-302 Decurler Door Intlk Sw. The state of the Decurler Door Interlock
Switch is Low and switches to High when the Decurler Door is opened.
YN
With the Front Cover closed, there is +0 VDC between P/
J1028-B6 on
the Finisher
PWB and GND.
YN
Go to the Fl
ag
1 and Flag 2 on BSD12.1. Check the wires for an open circuit. If the
wires are good, replace the Decurler Door Interlock Switch (PL 18.11). If the problem
continues, replace the Decurler PWB (PL 18.6). If the problem continues, replace
the Finisher PWB (PL 18.4).
Check the Decurler Door Interlock Switch for intermittent operation. Ensure that the
swit
ch and the cover
are properly aligned and adjusted. If the problem continues, replace
the Decurler PWB (PL 18.6). If the problem continues, replace the Finisher PWB (PL
18.4).
Check the Decurler Door Interlock Switch for intermittent operation. Ensure that the switch and
t
he c
over are properly aligned and adjusted. If the problem continues, replace the Finisher
PWB (PL 18.4).
11-303 Docking Interlock Open RAP
Docking Interlock Open failure. This status code is declared when the Mailbox is not properly
docked.
Initial Actions
• Refer to BSD12.1 for the following procedure.
• Ensure that P/J
1028 on the Finisher PWB, P/J664 and P/J665 on the Docking Interlock
Switches, P/J651 and P/J652 on the Decurler PWB are connected before beginning this
RAP.
• Check the Finisher/Mailbox
fo
r proper alignment.
Procedure
Enter dC330 012-303 Mailbox Docking INTLK Switches. The status of the Docking Inter-
lock Switches is High and changes to Low when the Mailbox is undocked.
YN
With the Finisher/Mailbox docked, there is +5 VDC between P/
J1028-B
7 on the Fin-
isher PWB and GND.
YN
Disconnect P/
J665 f
rom the Docking Interlock Switch 2. With the Finisher/Mail-
box docked, there is +5 VDC between P/J1028-B7 on
the Finisher PWB and
GND.
YN
Disconnect P/
J664 f
rom the Mailbox Docking Interlock Switch 1. With the Fin-
isher/Mailbox docked, there is +5 VDC between P/J1028-B
7 on the Fin-
isher PWB and GND.
YN
Go to the F
lag 10
, Flag 11 and Flag 13 on BSD12.1. Check the wires for
an short circuit to ground. If the wires are good, replace the Finisher PWB
(PL 18.4).
Replace the Docking Interlock Switch 1 (PL
18.6).
Replace t
he Docking Interlock Switch 2 (PL 18.6).
Check
the Docking Interlock Switches for intermittent operation. Ensure that the switches
are properly aligned
and adjusted. If the problem continues, replace the Finisher PWB
(PL 18.4).
Check the Mailbox Door Interlock Switch for intermittent operation. Ensure that the switch and
t
he
cover are properly aligned and adjusted. Check that the Finisher/Mailbox is standing on an
even floor. Adjust Castors if necessary. If the problem continues, replace the Mailbox PWB (PL
18.11).
