DocuColor 12/DCCS50
11-919 Bin 9 Full Stack RAP, 11-920 Bin 10 Full
Finisher/Sorter
Reissue
11-919 Bin 9 Full Stack RAP
The Control Logic detected that Bin 9 is full.
Initial Actions
• Refer to BSD12.9 for the following procedure.
• Ensure that Bin 9 is empty
Procedure
Enter dC330 012-289 Bin 9 Full Sensor. Press Start. Manually move the actuator in and out of
the sensor The display Changes from H to L to H as the actuator is moved in and out of
the s
ensor.
YN
Press Stop. +5VDC is measured between P
/J1002-
9 and DC COM on the Mailbox
PWB.
YN
+5VDC is measured between P/
J1031-3 and
DC COM on the Finisher PWB.
YN
Replace the Finisher PWB (PL 18.4).
Go to Fl
ag 9 on
BSD12.9 and check the wires for an open circuit.
Replace the Mailbox PWB (PL 1
8.11).
Check the Bin 9 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mailbox PWB (PL 18.11).
11-920 Bin 10 Full Stack RAP
The Control Logic detected that Bin 10 is full.
Initial Actions
• Refer to BSD12.9 for the following procedure.
• Ensure that Bin 10 is empty
Procedure
Enter dC330 012-290 Bin 10 Full Sensor. Press Start. Manually move the actuator in and out
of the sensor The display Changes from H to L to H as the actuator is moved in and out
of t
he sensor.
YN
Press Stop. +5VDC is measured between P
/J1
002-10 and DC COM on the Mailbox
PWB.
YN
+5VDC is measured between P
/J1031
-2 and DC COM on the Finisher PWB.
YN
Replace the Finisher PWB (PL 18.
4).
Go
to Flag 10 on BS
D12.9 and check the wires for an open circuit.
Replace the Mailbox PWB (PL 18.11
).
Check the Bin 10 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mailbox PWB (PL 18.11).
