1/05
6-27
DocuColor 12/DCCS50
dC131 NVM Read/Write, dC131 UI/Tools (700)
General Procedures
Reissue
NOTE: Values that are out of range will cause the Error Tab to turn “Red”.
NOTE: While a value is highlighted, you can write an NVM value in it.
Writing NVM
1. To write a new value, first enter a new value in the "New" column
2. Select Wr
it
e NVM.
a. If the input value is valid (within the range), the system writes the new NVM value in
the NVM code
in the machine.
b. If the input value is invalid, the system displays the following message in the informa-
tion screen, “The given NVM value is out of range. NVM was not changed”.
c. If the NVM cannot be changed (Write protected NVM), the system displays the fol-
lowing message, “! The specified NVM is read only”.
d. When the system writes the new value in the specified NVM code, the value is
updat
ed
in the “New Box” and reduces the count in the “Changed Tab”.
NOTE: When a value is written in the vertical “Changed Tab”, the tab will turn green.
The
number in “parenthesis“() will count the number of pending NVM values. Click-
ing the tab once will show a list of all the changed values. If a new value is input but
not
yet
written, the changed value is captured in the “Changed” Vertical Left Tab List.
dC131 UI/Tools (700)
Table 1 UI/Tools (700)
Chain-
Link Name Def
ault Range Description
700-091 Customer Paper Size FS 200 0-297 Free Paper Size Registration (FS)
700-092 Customer Paper Size SS 300 0-432 Free Paper Size Registration (SS)
700-093 Equal Magnification -
Fine Adjust
ment (FS)
20 0-40 98-102%. In 0.1% increments.
The equation is (98+(set value x
0.1)).
Default of 20 = 100%
From IOT S/W 6.00.2, can be set in
t
ools m
ode
700-094 Equal Magnification -
Fine Adjust
ment (FS)
0 0-40 98-102%. In 0.1% increments.
The equation is (98+(set value x
0.1)).
Default of 20 = 100%
700-096 PA Entry Key - Coin Kit 0 0-1 To enable or disable PA Entry Key
Display (for
Coin Kit)
0= OFF
1= ON
700-097 ACS Platen Start Check 0 0-1 0= Check on
1= Check off
700-098 Tray 5 Paper Size 1 0-5 0= Heavyweight Paper/Tracking
f
ilm.
1= Heavyw
eight Paper, duplex (MN
def
aul
t.
2= Labels.
3= Label/tracing paper.
4= Duplex middle weight.
5= Label/Duplex heavy weight
p
aper.
700-099 UI
Post Flag 1 0-1 UI Flag - enables features such as
P
ost
ers, Cover Sheets, HCF
0= Poster Flag Off
1= Poster Flag On
700-100 Lighter - Darker Default 3 0-7 Copy Density Setup (Prevents
copy
ing see-
thru image)
700-101 Hue Control Default 3 0-5 1= 20
2= 10
3= 0
4= 10
5= 20
700-102 Chroma Control Default 0 0-5
700-103 Sharpness Default 0 0-5
700-104 Color Balance Default (Y
Hi
gh
)
0 0-7 Copy Density Setup (Prevents
copying see thru image)
700-105 Color Balance Default (Y
Middle)
0 0-7 Copy Density Setup (Prevents
copying see-
thru image)
