DocuColor 12/DCCS50
dC131 IIT NVM List (715, 719)
Reissue
General Procedures
dC131 IIT NVM List (715, 719)
Table 1 IIT NVM List (715, 719)
Chain-
Link Nam
e Default Range Description
715-012 BW/Color automatic rec-
ognition level adjust-
ment
2 0-4 Level 0 (B/W) - Level 4 (Color)
715-023 PMadjF 50 0-100 Main scanning direction: Magni-
fication correction value (Digital
corr
ecti
on by ASCI: Low ACS/TI
separation)
715-028 DADF FS offset 32 0-100 Side Registration Offset when
DAD
F
is used (0.6mm/step)
Side Registration correction
value (Dot
/s
etp)
715-029 PRadjF 50 0-100 Main scanning direction - REJI
correcti
on value (Dot)
715-062 AOCerr 0 0-255 Number of abnormal AOC flow
term
inations
715-091 Pshad(1) 150 115-255 Red W-Ref correction factor
715-092 Pshad(2) 160 115-255 Green W-Ref correction factor
715-093 Pshad(3) 167 115-255 Blue W-Ref correction factor
715-103 SB SCAN 220 0-255 b* Correction standard value
(Upper 8 bi
ts in the 10 bits)
715-106 HOSEI SCAN 3 0-6 Correction factor number
715-107 MB SCAN 0 0-511 Patch b* Measure value (9 bits
including overfl
ow)
715-110 CCD Calibration Y read:
Red
0 0-1023 CCD Calib
ration: Y patch read -
Red (Reflection rate LSB)
715-111 CCD Calibration Y read:
Gree
n
0 0-1023 CCD Calibration: Y patch read -
Green (Reflection rate LSB)
715-112 CCD Calibration Y read:
Blue
0 0-1023 CCD Cali
bration: Y patch read -
Blue (Reflection rate LSB)
715-113 CCD Calibration M read:
Red
0 0-1023 CCD Cali
bration: M patch read -
Red (Reflection rate LSB)
715-114 CCD Calibration M read:
Gree
n
0 0-1023 CCD Calibration: M patch read -
Green (Reflection rate LSB)
715-115 CCD Calibration M read:
Blue
0 0-1023 CCD
Calibration: M patch read -
Blue (Reflection rate LSB)
715-116 CCD Calibration C read:
Red
0 0-1023 CCD Cali
bration: C patch read -
Red (Reflection rate LSB)
715-117 CCD Calibration C read:
Gree
n
0 0-1023 CCD Calibration: C patch read -
Green (Reflection rate LSB)
715-118 CCD Calibration C read:
Blue
0 0-1023 CCD
Calibration: C patch read -
Blue (Reflection rate LSB)
715-119 CCD Calibration PK
read: Red
0 0-1023 CCD Calibration: PK patch read
- Red (Reflection rate LSB)
715-120 CCD Calibration PK
read: Gr
een
0 0-1023 CCD Calibration: PK patch read
- Green (Reflection rate LSB)
715-121 CCD Calibration PK
read: Blue
0 0-1023 CCD Calibrati
on: PK patch read
- Blue (Reflection rate LSB)
715-123 Side Registration Shift (-
)
0 0-256 Minus direction offset (Dot/step)
for Side Regis
tration adjustment/
check
715-124 A6 document/Postcard
check
0 0-1 0= A6 document, 1= Postcard
715-125 Platen/ADF 0 0-1 0= Platen 1= ADF
715-126 A4S/Letter document
size det
ect
ion
3 0-6 A4S/Letter document size
threshold
Default 3=213mm (Data 1=
2m
m change)
0 (Lett
er) - 6(A4S)
715-132 Sub-scanning direction:
Registra
tion correction
50 20-75 Sub-scanning direction: Lead
Registration correction
(0.076mm/step)
715-133 Sub-scanning direction:
Magnif
ic
ation correction
50 44-56 Scan magnification correction
(0.1%/step)
715-136 IIT Fault bypass 0 0-1 Fault bypass= 1, No fault
bypass=
0
715-137 PreIPS fault bypass 0 0-1 Fault bypass= 1, No fault
bypass=
0
715-165 DSWTh 780 0-1023 Platen half-open: White docu-
ment detection threshold
0= White 1023= Black
715-166 DSLTh 140 0-1023 Main scanning direction: Ladder
docum
ent det
ection threshold
Data: B/W change (Ladder edge
chang
e)
715-167 DSLNum 3 0-255 Ma
in scanning direction - Num-
ber of ladder detection threshold
Number of changes obtained in
715-166 3 =< Doc
ument,
<3= No
document
Table 1 IIT NVM List (715, 719)
Chain-
Lin
k Name Default Range Description
