10-359 Heat Roll Control Thermistor Failure RAP,
Status Indicator RAPs
Reissue
10-359 Heat Roll Control Thermistor Failure RAP
The Heat Roll Control Thermistor detected an abnormal resistance value continuously for more
than 1500 msec (Heat Roll Control Thermistor disconnected).
Initial Actions
Refer to BSD 10.2 and 10.12 for the following procedure.
• Open the Drawer and extend it to the service position. Perform the following:
– Remove the Oil Cartridge (PL 8.
1).
– Remove the Front Cover (PL 8.1).
–
Remove the Top Cover (PL 8.2).
• Check the Heat Roll Control Thermistor for cleanliness, damage and excessive wear at
the point
where the Thermistor contacts the Heat Roll. If the surface of the Thermistor is
worn, replace the Heat Roll Control Thermistor (PL 8.4). Inspect the surface of the Heat
Roll for excessive wear due to the Thermistor. Replace the Heat Roll if necessary (PL
8.3).
• Check the Drawer connector P700
B at t
he rear of the Fuser for damaged pins. Check the
mating connector on the IOT, and ensure that the mounting plate for the IOT connector is
not bent or misaligned.
Procedure
NOTE: Prior to replacing a component, disconnect the connectors to the component (Heat Roll
Control Thermistor and IOT Drive PWB). Check the connectors for broken, bent and dirty pins.
Disconnect and reconnect the connectors several times to remove contaminants due to oxida-
tion.
Switch the power off. Disconnect P/
J171 on t
he Heat Roll Control Thermistor. Measure the
resistance between P/J171-1 and P/J171-2 on the Heat Roll Control Thermistor. The resis-
tance of the Thermistor should be in the range of 0.78K Ohms when hot to 150K Ohms when
cool
(r
oom temperature). Note the measurement if it is in specification. The resistance of the
Ther
mistor is in specification.
YN
Replace the Heat Roll Control Thermistor (PL 8.4).
Reconnect P/
J1
71 to the Heat Roll Control Thermistor. Close the Drawer. Disconnect P/
J413A from the IOT Drive PWB. Measure the resistance from P/J413A-13 to P/J413A-7. The
resistan
ce measurement is the same as the measurement noted above (+/- 5%).
YN
Go to Fl
ag 1 and Fla
g 3 on BSD 10.2. Check the harness for an open circuit.
Replace the IOT Drive PWB (PL 9.2).
10-360 Heat Roll Overheat Thermistor Failure RAP
The Heat Roll Overheat Thermistor detected an abnormal resistance value continuously for
more than 1500 msec (Heat Roll Overheat Thermistor disconnected).
Initial Actions
Refer to BSD 10.2 and 10.12 for the following procedure.
• Open the Drawer and extend it to the service position. Perform the following:
– Remove the Oil Cartridge (PL 8.
1).
– Remove the Front Cover (PL 8.
1).
– Remove the Top Cover (PL 8.2).
•
Check the Heat Roll Overheat Thermistor for cleanliness, damage and excessive wear at
the
point where the Thermistor contacts the Heat Roll. If the surface of the Thermistor is
worn, replace the Heat Roll Overheat Thermistor (PL 8.4). Inspect the surface of the Heat
Roll for excessive wear due to the Thermistor. Replace the Heat Roll if necessary (PL
8.3).
• Check the Drawer connector P
700B at t
he rear of the Fuser for damaged pins. Check the
mating connector on the IOT, and ensure that the mounting plate for the IOT connector is
not bent or misaligned.
Procedure
NOTE: Prior to replacing a component, disconnect the connectors to the component (Heat Roll
Overheat Thermistor and IOT Drive PWB). Check the connectors for broken, bent and dirty
pins. Disconnect and reconnect the connectors several times to remove contaminants due to
oxidation.
Switch the power off. Disconnect P/
J172 on the Heat
Roll Overheat Thermistor. Measure the
resistance between P/J172-1 and P/J172-2 on the Heat Roll Overheat Thermistor. The resis-
tance of the Thermistor should be in the range of 0.78K Ohms when hot to 150K Ohms when
cool (room
t
emperature). Note the measurement if it is in specification. The resistance of the
Therm
istor is in specification.
YN
Replace the Heat Roll Overheat Thermistor (PL
8.
4).
Reconnect P/J172 t
o the Heat Roll Overheat Thermistor. Close the Drawer. Disconnect P/
J413A from the IOT Drive PWB. Measure the resistance from P/J413A-13 to P/J413A-8. The
resistan
ce measurement is the same as the measurement noted above (+/- 5%).
YN
Go to F
lag 1 and Fl
ag 2 on BSD 10.2. Check the harness for an open circuit.
Replace the IOT Drive PWB (PL 9.2).
