1/05
2-193
DocuColor 12/DCCS50
11-142 V-Tra In Sensor On Jam Long RAP, 11-143
Status Indicator RAPs
Reissue
Check the Drive Belt Tension Roll for proper tension.
Enter dC330 011-142 Vertical Transport In Sensor. Manually act
uate the V-Tra In Sensor
actuator. The display changes from L to H to L as the actuator moves in and out of the
sensor
.
YN
The display is always H
YN
Go to Fl
ag 1 on BS
D 11.4. Check the harness for a short circuit to ground. If the har-
ness is good, replace the V-Tra Sensor (PL 13.9).
+5
VDC is measured between P/J562-7 and
P/J562-9
YN
CR1 on the Mail Box Control PWB is on.
YN
Go to the +5 VDC wirenet and troubleshoot the wires between P/
J569-1 and
P/
J44-6 on the Distribution PWB.
Replace the Mail Box Control PWB (PL 13.10).
Go to Flag 1 and
Flag 3 on BSD11.4. Check the harness for an open circuit. If the harness
is good, replace the Oct Exit Sensor (PL 13.9).
With paper at the sensor, less than +0.5 VDC is measured between P/ P/J5
62-8 and
GND.
YN
Replace the V-Tra In Sensor (PL 13.
9).
Check t
he following parts for wear, glazing, or slipping.
• Entrance Roll (PL 1
3.9)
• Pinch Rollers (PL 1
3.9)
• Exit Roll (PL 13.9)
• Drive Belt (PL 13
.10)
Check the Drive Belt Tension Roll for proper tension.
11-143 V-Tra In Sensor Off Jam RAP
The V-Tra In Sensor did not deactuate within the specified time after the V-Tra In Sensor actu-
ated.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-143 M
ailbox
Entrance Sensor Off Jam RAP to troubleshoot this Fault Code.
Initial Actions
Refer to BSD 11.2 and 11.4 for the following procedure.
Check for the following:
• Obstructions in the Mail Box paper path
• Bent or out of position paper chutes/guides in the Mail Box paper path
• Ensure that the Mail Box front Door is closed proper
ly
, in order to provide proper nip pres-
sure to the Vertical Transport Rolls.
• Ensure that connectors P/J5
62 on the Mail Box Control PWB and P/J567 on the V-Tra In
Sensor are seated correctly and there are no obvious crimped or broken wires.
Procedure
The trail edge of the paper is past the Oct Exit Sensor
YN
Enter d
C330 011-005 Mailbox Drive Motor. Press St
art. The Mail Box Transport Roll
is rotating.
YN
The Mailbox drive Belt is moving.
YN
The Mail Box Drive Motor is rotating
YN
+24 VDC is measured between P/
J572-1
and P/J572-2 of the Mail
Box Drive Motor
YN
Switch Off the Power. Disconnect P/
J572 fro
m the Mail Box Drive
Motor. Switch On the Power. +24 VDC is measured between P/
J572-1 and P
/J572-2.
YN
Go to F
lag 1 on BSD11.2. Check the wires for an open circuit. If
th
e wires are good, replace the Mail Box Control PWB (PL
13.10).
Replace the Mail Box Drive Motor (PL 13.
10)
Pr
ess Stop. +5 VDC i
s measured between P/J572-3 and GND.
YN
Go to F
lag 3 on BSD 11.2. Check the wire for an open circuit. If the
wire i
s good, replace the Mail Box Control PWB (PL 13.10).
Press Start. Less th
an +1 VDC is measured between P/J572-3 and
GND.
A
A B C D
To Next Page
