Xerox DocuColor 12/DCCS50 User Manual

1/05
2-201
DocuColor 12/DCCS50
11-192 Paper Remains at OCT Exit Sensor RAP, 11-
Status Indicator RAPs
Reissue
11-192 Paper Remains at OCT Exit Sensor RAP
The Control Logic detected that paper remained on the Oct Exit Sensor at power on.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-192 P
aper
Remains at SCT Exit Sensor RAP to troubleshoot this Fault Code.
NOTE: Ensure that Sorter S-1 Tag is installed.
Initial Actions
• Refer to BSD11.4 for the following procedure.
• Ensure that no paper is blocking the OCT Exit sensor and
the sensor actuator moves
freely.
• Check for excessive static on copies.
• Check for any obstructions in the paper path.
• Ensure that P/J562 on the
Mail Box Control PWB, and P/J567 on the V-Tra In Sensor
are connected before beginning this RAP.
Procedure
Enter dC330 011-107 OCT Exit Sensor. Press Start. The display is L.
YN
Go to Fl
ag 2 on BS
D 11.4 and check the harness for a short circuit. If the harness is good,
replace the OCT Exit Sensor (PL 13.9).If the problem continues, replace the Mail Box
Control PWB (PL 13.10).
More than +4.3 VDC is measured between P
/J562-
5 and GND on the Mail Box Control
PWB.
YN
Replace the OCT Exit Sensor (P
L 1
3.9).
Check the OCT Exit Sensor for intermittent operation.
If the sensor is good, Replace the Mail
Box Control PWB (PL 13.10).
11-193 Decurler Exit Sensor Static Jam RAP
The Control Logic detected that paper remained on the Decurler Exit Sensor at power on.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-193 Dec
urler Exit
Sensor Static Jam RAP to troubleshoot this Fault Code.
NOTE: Ensure that Sorter S-1 Tag is installed.
Initial Actions
• Refer to BSD11.3 for the following procedure.
• Ensure that no paper is blocking the Decurler Exit sensor
• Ensure that P/J570 on t
he Mail Box Control PWB, Double Plug J571, P/J651 and P/
J654 on the Decurler Control PWB, and P/J658 on the Decurler Exit Sensor are con-
nected before beginning this RAP.
Procedure
Enter dC330 011-145 Decurler Exit Sensor. Press Start. The display is H.
YN
Go to F
lag 1 on BSD 1
1.3 and check the harness for a short circuit. If the harness is good,
replace the Decurler Exit Sensor (PL 13.12). If the problem continues, replace the Mail
Box Control PWB (PL 13.10).
More than +4.3 VDC is measured between P/
J654-
2 and GND on the Decurler Control
PWB.
YN
Replace the Decurler Exit Sensor (PL 13.
12).
Check
the Decurler Exit Sensor for intermittent operation. I
f the sensor is good, Replace the
Mail Box Control PWB (PL 13.10).
