1/05
2-76
DocuColor 12/DCCS50
Reissue
Status Indicator RAPs
Replace the Tray 4 No Paper Sensor (PL 2.5).
Replace the IOT Drive PWB (PL 9.2).
Check
/replace the following parts in the order listed unt
il the problem is resolved. Replace
any parts that are worn, broken, binding, or missing.
• Tray 4 Paper Feed Assembly (PL 2.4)
• Tray 4 Assembly (PL 2.
1)
• Wiring Harness
Check the wire harnesses and connectors of all the
Tray paper feed assemblies for an intermit-
tent problem.
7-502 Tray 5 Paper Size Mismatch (Width) RAP
The machine detected that the paper size width is not being detected correctly in Tray 5.
Initial Actions
•Perform ADJ 9.1.17.
• Refer to BSD 7.4 for the following procedure.
• Check for obstructions in the paper path.
• Go to the Control Panel, ensure that Tray 5 Paper Si
ze indicator is set to the correct paper
size loaded in Tray 5, and that the width guide is against the paper.
• Ensure that the NVM location for the Market is the correct country code, 752-001 = 2
Procedure
The paper size being utilized for this procedure matches the paper size selected on the
Touch Screen.
YN
Voltage is measured at P
/J146-
B15 on the IOT PWB and GND on the Tray 5 Size
Sensor.
YN
+5 VDC is measured between P
/J148
-3 on the Tray 5 Paper Size Sensor and
GND.
YN
Go to the +
5 VD
C Power (IOT LVPS) RAP.
Go to Flag 2 on BSD 7.4 and check the harness for an open circuit or short to GND.
If
the harness is OK, replace the Tray 5 Paper Size Sensor (PL 2.13).
Go to Flag 1 on BSD 7.4 and check the harness for an open circuit or short to GND. If the
harness i
s OK, replace the Tray 5 Paper Size Sensor (PL 2.13). If that does not correct
the problem, replace the IOT PWB (PL 9.2).
Check/replace the following parts in the order listed
until the problem is resolved. Replace any
parts that are worn, broken, binding, or missing.
• Spring (PL 2.13).
• L
ink (PL 2.13).
• T
ray 5 Size Sensor (PL 2.13).
• T
ray 5 Assembly (PL 2.
9).
D E F G
