Xerox DocuColor 12/DCCS50

1/05
2-103
DocuColor 12/DCCS50
8-179 Tray 4 Registration Sensor On Jam RAP, 8-
Status Indicator RAPs
Reissue
8-179 Tray 4 Registration Sensor On Jam RAP
The Registration Sensor did not actuate with 956 - 1056 msec after the feed started from Tray
4.
Initial Actions
• Refer to BSD 8.8 and BSD 8.10 for the following procedure.
• Check for any obstructions in the paper path.
Procedure
Enter dC330 008-155 Registration Sensor. Press Start. The display is H.
YN
+5 VDC is measure between P/
J421A-11 o
n the IOT Drive and GND.
YN
Go to Fl
ag 5 on BS
D 8.8 and check the harness for a short circuit. If the harness is
good, replace the Registration Sensor (PL 2.15).
Replace the IOT Drive PWB (PL 9.2).
Cheat
the Front Door Interlock. Open the Drawer and block the Registration Sensor with a
sheet of
paper. Carefully close the drawer. Enter dC330 008-155 Registration Sensor and
press Start. The display is L.
YN
There is +5 VDC between P
/J421A-
12 and P/J421A-10 on the IOT Drive PWB.
YN
Go to Fl
ag 5 on BS
D 8.8 and check the harness for a short circuit. If the harness is
good, replace the IOT Drive PWB (PL 9.2).
Go to Flag 5 and Fla
g 6 on BSD 8.8 and check the harness for an open circuit. If the har-
ness is OK, replace the Registration Sensor (PL 2.15). I
f the problem continues, replace
the IOT Drive PWB (PL 9.2).
Enter dC330 008-054 Registration Motor. Pre
ss Start. The Registration Motor energizes.
YN
Go to the R
egi
stration Motor RAP.
Check/replace the following components until the problem is resolved. Replace any compo-
nents that are worn, broken, binding, or slipping.
• Registration Roller and Roller, Springs, and Bearings in the Registration Assembly (PL
2.15)
•
Gear in the Registration Assembly (PL 2.1
5)
• Check for burrs on the Upper Chute and Chute in the Registration Assembly (PL 2.15).
8-305 Tray 5 Interlock Open RAP
The Tray 5 Interlock is detected open.
Initial Actions
Refer to BSD 7.4 and BSD 8.10 for the following procedure.
Procedure
Enter dC330 008-305 Tray 5 Interlock Switch. Press Start. Actuate, then deactuate, the Tray
5 Interlock Switch. The display changes from L when the switch is actuated to H when
the swi
tch is deactuated.
YN
Connect the meter from P
/J416B-9 on
the IOT Drive PWB to machine frame. Actuate,
then deactuate, the Tray 5 Interlock Switch. The voltage at P/J416B-9 g
oes from less
than +1.0 VDC when the switch is actuated, to +5.0 VDC when the switch is deactu-
ated.
YN
Go to Fl
ag 4 on BSD 7.
4 and check the harness for an open circuit. If the harness is
good, replace the Tray 5 Switch (PL 2.12).
Replace the IOT Drive PWB (PL 9.2).
I
f the fault code is present and can not be cleared, replace the IOT Drive PWB (PL 9.2)
. If the
fault code is not present and is occurring intermittently, go to Flag 4 on BSD 7.4 and check the
harness for an intermittent open circuit. If the harness is OK, replace the Tray 5 Switch (PL
2.12). If the problem continues, replace the IOT Drive PWB (PL 9.2).
