Xerox DocuColor 12/DCCS50 User Manual

1/05
2-151
DocuColor 12/DCCS50
10-160 Duplex In Sensor On Jam RAP, 10-162 Du-
Status Indicator RAPs
Reissue
10-160 Duplex In Sensor On Jam RAP
Duplex In Sensor Paper Static Jam.
Initial Actions
Refer to BSD 10.10 and 10.12 for the following procedure.
Check for the following:
• Clean the Duplex In Sensor (PL 2.
24).
• Ensure that connectors P/J412A and P/J
150 are seated correctly on the IOT Drive PWB
and the Duplex In Sensor, and there are no obvious crimped or broken wires.
• Ensure the Inverter is closed. Switch the power Off then On.
Procedure
Enter dC330 010-130 Duplex In Sensor. Press Start. The display indicates L.
YN
Go to Fl
ag 3 and Fl
ag 4 on BSD 10.10 and check the harness for a open circuit. If the har-
ness is good, replace the Duplex In Sensor (PL 2.24).
If the fault code is present and can not be cleared, replace the IOT Drive PWB (PL 9.
2). If the
fault code is not present and is occurring intermittently, go to Flag 3 and Flag 4 on BSD 10.10
and check the harness for an intermittent open circuit. If the harness is OK, replace the Duplex
In Sensor (PL 2.24). If the problem continues, replace the IOT Drive PWB (PL 9.2).
10-162 Duplex Path 1 Sensor On Jam RAP
Duplex Path Sensor Paper Static Jam.
Initial Actions
Refer to BSD 10.10 and 10.12 for the following procedure.
Check for the following:
• Clean the Duplex Path Sensor (PL 2.21).
• E
nsure that connectors P/J420 and
P/J154 are seated correctly on the IOT Drive PWB
and the Duplex Path Sensor, and there are no obvious crimped or broken wires.
• Ensure the Drawer is closed. Swi
tch the power Off then On.
Procedure
Enter dC330 010-132 Duplex Path Sensor. Press Start. The display indicates L.
YN
Go to F
lag 7 and Flag 8 on BSD 10.10 and check the harness for a open circuit. If the har-
ness
is good, replace the Duplex Pa
th Sensor (PL 2.21).
If the fault code is present and can not be cleared, replace the IOT Drive PWB (PL 9.2)
. If the
fault code is not present and is occurring intermittently, go to Flag 7 and Flag 8 on BSD 10.10
and check the harness for an intermittent open circuit. If the harness is OK, replace the Duplex
In Sensor (PL 2.21). If the problem continues, replace the IOT Drive PWB (PL 9.2).
