1/05
2-34
DocuColor 12/DCCS50
3-581 Dead Cycle Fail RAP, 3-600 Billing Adjust NVM
Reissue
Status Indicator RAPs
3-581 Dead Cycle Fail RAP
The Dead Cycle continued for more than two minutes.
Initial Actions
• Refer to BSD 3.12 Monitoring in this procedure:
Procedure
PO/PO the machine. Fault Code is still declared.
YN
Inspect the IOT CPU PWB and the IOT NVM PWB for loose connections or any obvious
elect
ri
cal/mechanical cause for malfunction.
Perform the following:
• Replace the IOT NVM PWB (PL 9.2)
• Replace the IOT CPU PWB (PL 9.
2)
3-600 Billing Adjust NVM Failure RAP
This Fault Code is declared when after the job ended, the billing mismatch occurred, and auto-
matic correction implemented.
Initial Actions
• Refer to BSD 3.12 Monitoring in this procedure:
Procedure
PO/PO the machine. Fault Code 3-600 is still declared.
YN
If intermittent operation is suspected, inspect the IOT CPU PWB and the IOT NVM PWB
f
or
loose connections or any obvious electrical/mechanical cause for malfunction.
Enter [DC122, Failure History]. If this failure has occurred m
any times, replace the IOT NVM
PWB (PL 9.2).
