1/05
2-124
DocuColor 12/DCCS50
9-372 Xerographic CRU (Drum) Not In Position RAP,
Reissue
Status Indicator RAPs
9-372 Xerographic CRU (Drum) Not In Position RAP
Xerographic CRU (Drum) not in Position. The Control Logic detected that the Xerographic CRU
(Drum) is not installed in the machine.
Initial Actions
Refer to BSD 9.1 for the following procedure.
Ensure that P/J42
2A on the IOT Drive PWB and P/J713 are connected and that the Xero-
graphic CRU (Drum) is properly installed before beginning this RAP.
Procedure
Go to Flag 8 on BSD 9.1. Check the harness for an open or a short circuit. If the harness is
good, replace the Xerographic CRU (Drum).
If the problem continues, replace the IOT Drive PWB (PL 9.2).
NOTE: Check GP 15 Setting the Machine for a Time & Materials (T & M) Account, t
o ensure
that the CRU is compatible with the machine service contract.
9-374 Waste Bottle Not In Position RAP
This status code is declared when the sensor detects the there is no Waste Bottle, or that the
Waste Bottle has been improperly installed.
Initial Actions
Refer to BSD 9.13 and BSD 9.15 for the following procedure.
Check that the Waste Bottle is in place, and that the act
uator is not deformed. Check the Waste
Toner Bottle Sensor for dirt or foreign matter.
Procedure
Enter dC330 009-249 Waste Bottle Position Sensor. Press Start. The Display is (L)
YN
Check the Waste Toner Bottle Sensor for intermittent operation. If there is intermittent
operat
ion, rep
lace the Waste Toner Bottle Sensor (PL 5.2). If the problem continues,
replace the IOT Drive PWB (PL 9.2).
Less than +1 VDC is measured between P/J413-B4 and GND on the IOT Drive PWB.
YN
Replace the IOT Drive PWB (PL
9.2).
Go
to Flag 2 on BS
D 9.13. Check the wire for a short circuit to ground. If the wire is good,
replace the Waste Toner Bottle Sensor (PL 5.2).
