1/05
2-90
DocuColor 12/DCCS50
8-120 Tray 4 Feed Out Sensor On Jam RAP, 8-122
Reissue
Status Indicator RAPs
YN
There is +5 VDC between P/J801B-
6 on the Tray PWB and GND.
YN
Go to Fl
ag 6 on BS
D 8.4 and check the harness for an open circuit. If the har-
ness is good, replace the IOT Drive PWB
Replace the Tray PWB (PL 9.3).
Replace the Tray 4 Takeaway Feed Clutch (PL 2.7
A).
Enter dC330 008-025 Take Away Motor. Pr
ess the Start button. The Takeaway Motor ener-
gizes.
YN
Go to the T
akeaway Motor RAP.
Check/
replace the following components until the problem is resolved. Replace any compo-
nents that are worn, broken, binding, or slipping.
• Pinch Rolls and Springs in the Left Cover (PL
2.
8)
• Tray 4 Feeder Assembly (PL 2.4)
8-122 Tray 4 Feed Out Sensor On RAP
The Tray 4 Feed Out Sensor detected paper when closing the Front Cover or when power was
switched on.
Initial Actions
• Refer to BSD 8.4 and BSD 8.10 for the following procedure.
• Check for any obstructions in the paper path.
Procedure
Enter dC330 008-120 Tray 4 feed out Sensor. Press Start. The display indicates L.
YN
Go to F
lag 3 and Fl
ag 4 on BSD 8.4 and check the harness for an open circuit. If the har-
ness is good, replace the Tray 4 Feed O
ut Sensor (PL 2.8).
If the fault code is present and can not be cleared,
replace the Tray PWB (PL 9.3). If the fault
code is not present and is occurring intermittently, go to Flag 3 on BSD 8.4 and check the har-
ness for an intermittent short circuit. If the harness is O
K,
ensure that the sensor actuator
moves freely. If the actuator is OK, replace the Tray 4 Feed Out Sensor (PL 2.8). If the problem
continues, replace the Tray PWB (PL 9.3).
A
