2-130

DocuColor 12/DCCS50

9-424 Cleaning Auger Near Full RAP, 9-601 Humidity

Reissue

Status Indicator RAPs

9-424 Cleaning Auger Near Full RAP

Control Logic has detected that the Cleaning Auger is almost full.

Initial Actions

This is a message fault only. An operator action is required

Procedure

This fault should not require any service action. If this fault causes a problem, use the 9-358

Cleaning Auger Full RAP to troubleshoot the problem.

9-601 Humidity Out Of Range RAP

The measured humidity was out of the prescribed range.

Initial Actions

• Refer to BSD 9.14 and BSD 9.15 for the following procedure.

• Check the Temp Humidity Sensor (PL 7.

1) for dirt or foreign matter

Check that the P/J142 on the T

emp Humidity Sensor, and P/J422A on the IOT Drive PWB

are firmly connected.

Procedure

+5 VDC is measured between P/J422B-2 and P/J422A-3 on the IOT Drive PWB.

Replace the IOT Drive PWB (PL

9.2).

to Flag 1 and F

lag 2 on BSD 9.14. Check the wires for an open circuit or a short circuit. If

the wires are good, replace the Temp Humidity Sensor (PL 7.1). If the problem continues,

replace the IOT Drive PWB (PL 9.2).
