DocuColor 12/DCCS50
Status Indicator RAPs
Reissue
7-501 Tray No Paper RAP
The machine detected no paper in the paper tray selected.
NOTE: This RAP should be used when the presenc
e of paper is not detected in any of the
Paper Trays or if the paper tray selected ran out of paper and the Auto Tray Selection (ATS)
could not find paper of the same orientation from another tray to finish the job.
Initial Actions
Check the following items for dirt, binding, freedom of movement or excessive wear: Tray No
Paper Sensor, Tray Level Sensor, and Tray Nudger Solenoid.
• Verify that the Trays are not jammed.
• Ensure that all paper sizes are correct.
• Ensure paper is properly loaded in the Trays.
• Ensure all paper Trays are closed.
Procedure
Select Tray 1 on the Control Panel while observing the UI. Paper is detected in Tray 1 and
the message Ready to Copy appears.
YN
Enter d
C330 008-231 Tray 1 No Paper Sensor. Pr
ess Start. Manually actuate the Tray
1 No Paper Sensor. The display changed from L to H.
YN
+0 VDC is measured at P
/J414A-
7 on the IOT Drive PWB.
YN
+5 VDC is measured at P
/J129
-2 on the Tray 1 No Paper Sensor.
YN
Go to Fl
ag 1 and Fla
g 2 on BSD 7.5 and check the harness and connec-
tors. If the harness and connectors are OK, replace the IOT Drive PWB.
Replace the Tray 1 No Paper Sensor (PL 2.5).
Replace the IOT Drive PWB (PL 9.2).
Check
/replace the following parts in the order listed unt
il the problem is resolved. Replace
any parts that are worn, broken, binding, or missing.
• Tray 1 Paper Feed Assembly (PL 2.4)
• Tray 1 Assembly (PL 2.
1)
• Wiring Harness
Select Tray 2 on the Control Panel while observing the UI. Paper is detected in Tray 2 and
the messag
e Ready to Copy appears.
YN
Enter d
C330 008-232 Tray 2 No Paper Sensor. Pr
ess Start. Manually actuate the Tray
2 No Paper Sensor. The display changed from L to H.
YN
+0 VDC is measured at P
/J415A-
16 on the IOT Drive PWB.
YN
+5 VDC is measured at P
/J129
-2 on the Tray 2 No Paper Sensor.
YN
Go to Flag 1 and Fl
ag 2 on BSD 7.6 and check the harness and connec-
tors. If the harness and connectors are OK, replace the IOT Drive PWB.
Replace the Tray 2 No Paper Sensor (PL 2.5).
Replace the IOT Drive PWB (PL 9.
2).
Check/replace the following parts in the order listed until
the problem is resolved. Replace
any parts that are worn, broken, binding, or missing.
• Tray 2 Paper Feed Assembly (PL 2.4)
•
Tray 2 Assembly (PL 2.
1)
• Wiring Harness
Select Tray 3 on the Control Panel while observing the UI. Paper is detected in Tray 3 and
the messag
e Ready to Copy appears.
YN
Enter dC330 008-233 Tray 3 No Paper Sensor. Press Sta
rt
. Manually actuate the Tray 3
No Paper Sensor. The display changed from L to H.
YN
+0 VDC is measured at P
/J415A-13 o
n the IOT Drive PWB.
YN
+5 VDC is measured at P
/J129-
2 on the Tray 3 No Paper Sensor.
YN
Go to Fl
ag 1 and Fl
ag 2 on BSD 7.7 and check the harness and connec-
tors. If the harness and connectors are OK, replace the IOT Drive PWB.
Replace the Tray 3 No Paper Sensor (PL 2.5).
Replace the IOT Drive PWB (PL 9.
2).
Check/replace the following parts in the order listed until
the problem is resolved. Replace
any parts that are worn, broken, binding, or missing.
• Tray 3 Paper Feed Assembly (PL 2.4)
•
Tray 3 Assembly (PL 2.
1)
• Wiring Harness
Select Tray 4 on the Control Panel while observing the UI. Paper is detected in Tray 4 and
the messag
e ready to copy appears.
YN
Enter d
C330 008-234 Tray 4 No Paper Sensor. Pre
ss Start. Manually actuate the Tray 4
No Paper Sensor. The display changed from L to H.
YN
+0 VDC is measured at P
/J415A-10 o
n the IOT Drive PWB.
YN
+5 VDC is measured at P
/J129-
2 on the Tray 4 No Paper Sensor.
YN
Go to Fl
ag 1 and Fl
ag 2 on BSD 7.8 and check the harness and connec-
tors. If the harness and connectors are OK, replace the IOT Drive PWB.
A
A
B
B
C
C
D E F G
