1/05
3-25
DocuColor 12/DCCS50
IQ 19 Bead Carryout RAP, IQ 20 IOT Graininess
Image Quality
Reissue
• Replace the problem Developer Housing (PL 6.6)
IQ 20 IOT Graininess RAP
IOT Graininess RAP. This RAP is used when the output copy shows graininess, or a sandy, tex-
tured appearance.
Procedure
• Paper outside the specified weight and quality range can increase graininess. Heavy
weight papers are particularly susceptible.
• Replace the paper currently in use with new, 24 lb. Xe
rox COLOR Xpressions (NASG), or
90 GSM Colortech + (ESG) paper. If the paper change does not fix the problem, go to
Detailed Maintenance Activities in Section 1. Check the expected life of the Yellow,
Magenta, Cyan and Black Developer. If the developer material is past expected life,
replace it.
• Replace the Developer Bias Brush, if damaged (REP
6.1.
4)
• Replace the Developer Housing, if damaged (PL 6.6).
•G
o to IQ 37
Developer Bias HVPS RAP.
NOTE: After replacing developer material, go to IQ47 ATC Sensor RAP, Appendix 1.
ATC
set-up procedure.
Table 1 Data Collection
ADC
Targ
ets
Column 1
Humidity
Ad
ju
sted
ADC
Targets
Column 2
ADC Patch
R
eadi
ngs
Column 3
Y 773-266 773-281 773-606
M 773-267 773-282 773-607
C 773-268 773-283 773-608
K 773-269 773-284 773-609
To Next Page
