11-302 Front Cover B Interlock Open RAP, 11-303
Reissue
Status Indicator RAPs
11-302 Front Cover B Interlock Open RAP
Front Cover B Interlock Open Failure. This status code is declared when the Mail Box Front
Cover is open.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-302 Dec
urler
Door Interlock Open RAP to troubleshoot this Fault Code.
Initial Actions
• Refer to BSD11.1 for the following procedure.
• Ensure that P/J55
1 on the Mail Box Control PWB, and P/J564 on the Mail Box Front
Cover Interlock Switch are connected before beginning this RAP.
• Check the Front Cover for proper alignment.
• Verify that the Front Cover closes properly.
Procedure
Enter dC330 011-301 Mailbox Front Cover Intlk Sw. The state of the Mail Box Front Cover
Interlock Switch is Low and switches to High when the Mail Box Front Cover is opened.
YN
With the Front Cover closed, there is +0 VDC between P
/J551-
2 on the Mail Box
Control PWB and GND.
YN
Go to the F
lag 1
on BSD 11.1. Check the wires for an open circuit. If the wires are
good, replace the Mail Box Front Cover Interlock Switch (PL 13.4). If the problem
continues, replace the Mail Box Control PWB (PL 13.10)
Check the Mail Box Front Cover Interlock Switch for intermittent operation. Ensure that the
swit
ch and the cover
are properly aligned and adjusted. If the problem continues, replace
the Mail Box Control PWB (PL 13.10).
Check the Mail Box Front Cover Interlock Switch for intermittent operation. Ensure that the
swit
ch and th
e cover are properly aligned and adjusted. If the problem continues, replace the
Mail Box Control PWB (PL 13.10).
11-303 Docking Interlock Open RAP
Docking Interlock Open failure. This status code is declared when the Mail Box is not properly
docked.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-303 Doc
king
Interlock Open RAP to troubleshoot this Fault Code.
Initial Actions
• Refer to BSD11.1 for the following procedure.
• Ensure that P/J570 on the Ma
il Box Control PWB, P/J665 and P/J664 on the Mail Box
Docking Interlock Switches, and P/J652 on the Decurler Control PWB are connected
before beginning this RAP.
• Check the Mail Box for proper alignment.
Procedure
Enter dC330 011-303 Mailbox Docking INTLK Switches. The status of the Mail Box
Docking Interlock Switches is High and changes to Low when the Mail Box is undocked.
YN
With the Mail Box docked, there is +5 VDC between P
/J57
0-B7 on the Mail Box
Control PWB and GND.
YN
Disconnect P/
J665 f
rom the Mail Box Docking Interlock Switch 2. With the Mail
Box docked, there is +5 VDC between P/J570-B7 on the Mail Box Control PWB
and GND.
YN
Disconnect P/
J664 f
rom the Mail Box Docking Interlock Switch 1. With the
Mail Box docked, there is +5 VDC between P/J570-B7 on the Mail Box
Control PWB and GND.
YN
Go to the F
lag 2
on BSD 11.1. Check the wires for an short circuit to
ground. If the wires are good, replace the Mail Box Control PWB (PL
13.10).
Replace the Mailbox Docking Interlock Switch 1 (P
L 13.12
).
Replace the Mailbox Docking Interlock Switch 2 (PL 13.12
).
Check the Mail Box Docking Interlock Switches for intermittent operation. Ensure that the
switches are properly ali
gned and adjusted. If the problem continues, replace the Mail Box
Control PWB (PL 13.10).
Check the Mail Box Front Cover Interlock Switch for intermittent operation. Ensure that the
switch and the cover
are properly aligned and adjusted. Check that the Mail Box is standing on
an even floor. Adjust Castors if necessary. If the problem continues, replace the Mail Box Con-
trol PWB (P
L 1
3.10).
