ADJ 2.1
High Capacity Feeder
Reissue
Figure 2 Adjusting the Registration
NOTE: Ensure that both sides of the High Capacity Feeder are positioned at the same point on the scales before tightening the screws.
1. Loosen Two Screws on Both Sides
Scale
2. Adjust the Tray
Front Cover Alignment Screws
