1/05
8d-35
DocuColor 12/DCCS50
12-121
Finisher/Sorter
Reissue
YN
Check the gears and pulleys.
Check the following parts for wear, glazing, or slipping:
• Lower Exit Chute (PL 18.14)
• E
xit Roll (PL 18.14)
• E
xit Roll Belt (PL 18
.14)
• Compiler Drive Belt (PL 18.9
)
NOTE: The output of the Compiler Enter Sensor is Low when the sensor is blocked, and High
when the se
nsor is not blocked. Paper on the sensor moves the actuator away from the sen-
sor, unblocking it.
Enter dC330 012-120 Compiler Entrance Sensor. Press Sta
rt.
Manually actuate the Compiler
Entrance Sensor. The display changes from Low to High to Low as the actuator moves in
and o
ut of the sensor.
YN
The display is always Low.
YN
Disconnect P/
J10
52. There is +5 VDC from J1052-1 to J1052-3.
YN
+5 VDC is measured from P/
J1039-1 to P/
J1039-3.
YN
+5 VDC is measured from P/
J1026-3 to P/
J1026-2.
YN
Go to F
lag 17 on BS
D 12.1. Check the +5VDC wiring for an open cir-
cuit.
Replace the Finisher PWB (PL 18.4).
Go to Flag 9 on BSD
12.7. Check the harness for an open circuit.
There is +5 VDC from J1052-2 to J1052-3.
YN
Go to F
lag 10 on BS
D 12.7. Check the harness for an open circuit. If the wire is
good, replace the Finisher PWB (PL 18.4)
Replace the Compiler Entrance Sensor (PL 18.14).
If the problem continues, replace
the Finisher PWB (PL 18.4).
Disconnect P/J10
52. The display is High.
YN
Go to F
lag 10 on
BSD12.7. Check the wire for a short circuit to GND. If the wire is
good, replace the Finisher PWB (PL 18.4)
Replace the Compiler Entrance Sensor (PL 18.14).
Check
the actuator for the Compiler Entrance Sensor for binding as
it moves in and out of the
sensor. The actuator is binding.
YN
Check for obvious damage, missing and/or broken D
ri
ve Motor gear assemblies and drive
belts that would cause the copy to be slow to actuate the sensor.
Replace the Compiler Entrance Sensor (PL 18.14).
A
To Next Page
