Xerox DocuColor 12/DCCS50 User Manual

1/05
8d-37
DocuColor 12/DCCS50
12-180 , 12-181
Finisher/Sorter
Reissue
12-180 RAP
The Compiler Entrance Sensor detects a sheet of paper present in standby or at initialization.
Initial Actions
Refer to BSD 12.1 and BSD 12.7 for the following procedure.
Check the Finisher Transport paper path for uncleared jams or obst
ructions. If no obstruction or
paper is found, continue with this RAP.
Procedure
Enter dC330 012-120 Compiler Entrance Sensor. Press Start. Manually actuate the Compiler
Entrance Sensor. The display changes from Low to High to Low as the actuator moves in
and o
ut of the sensor.
YN
The display is always Low.
YN
Disconnect P/
J10
52. There is +5 VDC from J1052-1 to J1052-3.
YN
+5 VDC is measured from P/
J1039-1 to P/
J1039-3.
YN
+5 VDC is measured from P/
J1026-3 to P/
J1026-2.
YN
Go to F
lag 17 on BS
D 12.1. Check the +5VDC wiring for an open cir-
cuit.
Replace the Finisher PWB (PL 18.4).
Go to Flag 9 on BSD
12.7. Check the harness for an open circuit.
There is +5 VDC from J1052-2 to J1052-3.
YN
Go to F
lag 10 on BS
D 12.7. Check the harness for an open circuit. If the wire is
good, replace the Finisher PWB (PL 18.4)
Replace the Compiler Entrance Sensor (PL 18.14).
If the problem continues, replace
the Finisher PWB (PL 18.4).
Disconnect P/J10
52. The display is High.
YN
Go to F
lag 10 on
BSD12.7. Check the wire for a short circuit to GND. If the wire is
good, replace the Finisher PWB (PL 18.4)
Replace the Compiler Entrance Sensor (PL 18.14).
Check
the Compiler Entrance Sensor Actuator for binding as it moves in and out of the sensor.
12-181 RAP
The Compiler Paper Sensor detects a sheet of paper present at power up or at Job Complete.
Initial Actions
Refer to BSD 12.1 and BSD 12.11 for the following procedure.
Check the Compiler Tray for uncleared jams or obstruct
ions. If no obstruction or paper is found,
continue with this RAP.
Procedure
Enter dC330 012-252 Compiler Paper Sensor. Press Start. Manually actuate the Compiler
Paper Sensor. The display changes from Low to High to Low as the actuator moves in
and o
ut of the sensor.
YN
The display is always Low.
YN
Disconnect P/
J1048. T
here is +5 VDC from J1048-1 to J1048-3.
YN
+5 VDC is measured from P
/J1035
-10 to P/J1035-8.
YN
+5 VDC is measured from P
/J1026
-3 to P/J1026-2.
YN
Go to F
lag 17 on BSD 12.1. Check the +5VDC wiring for an open cir-
cuit
.
Replace the Finisher PWB (PL 18.4).
Go
to Flag 3 on BS
D 12.11. Check the harness for an open circuit.
There is +5 VDC from J1048-2 to J1048-3.
YN
Go to Fl
ag 4 on BS
D 12.11. Check the harness for an open circuit. If the wire is
good, replace the Finisher PWB (PL 18.4)
Replace the Compiler Paper Sensor (PL 18.16
). If the problem continues, replace
the Finisher PWB (PL 18.4).
Disconnect P/J1048. Th
e display is High.
YN
Go to Fl
ag 4 on BSD12.
11. Check the wire for a short circuit to GND. If the wire is
good, replace the Finisher PWB (PL 18.4)
Replace the Compiler Paper Sensor (PL 18.16
).
Check the actuator for the Compiler Paper Sensor for
binding as it moves in and out of the sen-
sor. If the actuator is binding, replac
e the Compiler Paper Sensor (PL 18.16).
