12-243 RAP
The Staple Ready Sensor does not detect the Staple sheet in the Ready position just prior to
stapling, or within 13 dummy staplings at Stapler initialization.
Initial Actions
Refer to BSD 12.13 for the following procedure:
• Ensure that connector P/J1092 is se
ated correctly to the Stapler Assembly, that connec-
tor P/J1044 is
seated correctly to the Finisher PWB and that there are no obvious
crimped or broken wires on either connector.
• Ensure that the Staple Cartridge contains staples and that it is correctly installed in the
Stapl
er Assembly.
Procedure
Remove, then reinstall, the Staple Cartridge. Enter dC330 012-273 Staple Ready Sensor.
Press Start. The display indicates Low.
YN
Go to Fl
ag 7 on BS
D 12.13. Check the wires for an open circuit or a short circuit to GND.
If the wires are good, go to Flag 4 on BSD 12.13. Check the wire for an open circuit. If the
wire is good, replace the Stapler Assembly (PL 18.17).
The Stapler Assembly appears to be operating correctly. If the problem continues, replace the
Stapl
e Cartridge and test the system. If the problem continues, replace the Stapler Assembly
(PL 18.17).
12-244 RAP
The Staple Head Home Sensor does not detect the Stapler in the home position within 600 ms
from the start of Stapler Motor reverse.
Initial Actions
Refer to BSD 12.13 for the following procedure:
• Ensure that connector P/J1092 is seat
ed correctly to the Stapler Assembly, that connec-
tor P/J1044 is
seated correctly to the Finisher PWB and that there are no obvious
crimped or broken wires on either connector.
• Check for staple jams.
Procedure
Remove the Stapler Cover Assembly (REP 15.3.3). Remove the Staple Cartridge. Push the
Staple Assembly toward the rear of the Finisher until the semicircular cam on the front of the
assembly is facing forward. Rotate the cam in a clockwise direction until the flat portion of the
cam is facing up. Enter dC330 012-273 Staple Ready Sensor. Press Start. The display indi-
cates High.
YN
Disconnect P/
J1092
from the Stapler. The display indicates High.
YN
Go to F
lag 2 on BSD 12.13. Check the wire for a short circuit to GND. If the wire is
good, replac
e the Finisher PWB (PL 18.4).
Replace the Stapler Assembly (PL 18.17).
Rot
ate the cam in a clockwise direction until the flat portion of the cam is facing down. The
disp
lay changes to Low.
YN
Disconnect P/
J1092
from the Stapler. +5 VDC is measured between J1092-9 and
GND.
YN
Go to Fl
ag 2 on
BSD 12.13. Check the wire for an open circuit. If the wire is good,
replace the Finisher PWB (PL 18.4).
Go to Flag 7 on BSD 12.13. Check the wires for an open circuit or short circuit to GND. If
th
e wires are good, replace the Stapler Assembly (PL 18.17).
Replace the Stapler Assembly (PL 18.17).
If the problem continues, replace the Finisher PWB
(PL 18.4).
