Xerox DocuColor 12/DCCS50 User Manual

1/05
8d-47
DocuColor 12/DCCS50
12-255, 12-256
Finisher/Sorter
Reissue
YN
Remove the Stacker Motor Belt. Enter dC330012-041 Stacker Motor Down and press
Star
t. The Stacker Motor rotates.
YN
Go to F
lag 15 and F
lag 16 on BSD 12.15 Check for an open circuit or a short to
GND. If the wires are good, replace the Stacker Motor (PL 18.26) If the problem con-
tinues, replace the Finisher PWB (PL 18.4).
Ensu
re that the gears in the Stacker Motor Assembly are installed correctly, and are free
fro
m damage.
Ensure that the Front and Rear Stacker Tray Drive Belts are installed correctly (refer to
RE
P 15.2.
9).
The problem appears to be intermittent. Go to Flag
3, Flag 4, Flag 7, Flag 15, and Flag 16 on
BSD 12.15. Check the circuits of the Stacker Motor and the Stacker Upper Limit Sensor for a
loose connection or an intermittent short circuit to GND.
12-256 RAP
The Stacker Lower Limit Sensor detects the Stacker Tray at the lower limit during ascension, or
does not detect a change of state during ascension.
Initial Actions
Refer to BSD 12.1 and 12.15 for the following procedure
Procedure
Remove the Rear Lower Cover. The Stacker Lower Limit Sensor is blocked by the Actua-
tor.
YN
Enter dC330 012-260 Stacker Lower Limit Sensor. Press St
art.
Manually actuate the
Stacker Lower Limit Sensor. The display changes from Low to High to Low.
YN
The display is always Low.
YN
Disconnect P/
J1066. T
here is +5 VDC from J1066-1 to J1066-3.
YN
+5 VDC is measured from P
/J1038
-5 to P/J1038-6.
YN
+5 VDC is measured from P
/J1026
-3 to P/J1026-2.
YN
Go to F
lag 17 on BSD 12.1. Check the +5VDC wiring for an
open circuit.
Replace t
he Finisher PWB (PL 18.4).
Go
to Flag 5 and Fl
ag 7 on BSD 12.15. Check the harness for an open cir-
cuit.
There is +5 VDC from J1066-2 to J1066-3.
YN
Go to Fl
ag 6 on BS
D 12.15. Check the harness for an open circuit. If the
wire is good, replace the Finisher PWB (PL 18.4)
Replace the Stacker Upper Limit Sensor (PL 18.27
). If the problem continues,
replace the Finisher PWB (PL 18.4).
Disconnect P/J1066. Th
e display is High.
YN
Go to F
lag 6 and Flag 7 on BSD12.15. Check the wire for a short circuit to
GND.
If the wire is good, replace the Finisher PWB (PL 18.4)
Replace the Stacker Lower Limit Sensor (PL 18.27
).
Go to Flag 5 and Fl
ag 6 on BSD 12.15. Check for a loose connection or an intermittent
short circuit to GND. If the wires are good, replace the Stacker Lower Limit Sensor (PL
18.27).
Enter dC330 012-040 Stacker Motor Up and press Start. T
he Stacker Tray moves up.
