1/05
2-195
DocuColor 12/DCCS50
11-144 V-Tra In Sensor On Jam Short RAP
Status Indicator RAPs
Reissue
Go to Flag 6 on BSD 11.4. Check the wires for an open circuit. If the wires
are good, ensure that the OCT gate is connected to the OCT Gate Sole-
noid and that it moves freely. If the problem continues replace the OCT
Ga
te
(PL 13.9) and the OCT Gate Solenoid (PL 13.9).
Ensure that the OCT gate is connected to the OCT Gate Solenoid and that it
moves f
reely. If the problem continues replace the OCT Gate (PL 13.9) and the
OCT Gate Solenoid (PL 13.9).
• Check the paper path for any obstructions t
hat
could cause the paper not to
enter the Vertical Transport.
• Ensure that the OCT gate moves freely. If the problem continues replace the
OCT Gat
e (PL 13.9) and the OCT Gate Solenoid (PL 13.9).
Enter dC330, 011-005 Mailbox Drive Motor. Pr
ess Start. The Mail Box Transport Roll
is rotating.
YN
The Mail Box Drive Belt is moving.
YN
The Mail Box Drive Motor is rotating
YN
+24 VDC is measured between P/
J572-1 and
P/J572-2 of the Mail
Box Drive Motor
YN
Go to F
lag 1 on BSD11.2. Check the wires for an open circuit. If the
wires are good, replace t
he Mail Box Control PWB (PL 13.10).
Press Stop. +5
VDC is measured between P/J572-3 and GND.
YN
Go to F
lag 3 on BSD 11.2. Check the wire for an open circuit. If the
wire is good,
replace the Mail Box Control PWB (PL 13.10).
Press Start. Less th
an +1 VDC is measured between P/J572-3 and
GND.
YN
Replace the Mail Box Control PWB (PL 13.
10)
Replace t
he Mail Box Drive Motor (PL 1
3.10).
Ensure that the Mail Box Drive Motor Pulley is fastened to the motor shaft.
• Check the Drive Belt Tension Roll for proper tension.
• Check the Drive Belt for Damage
• Check that the gear pulleys are properly f
as
tened to the drive rolls
Check the following parts for wear, glazing, or slipping.
• Entrance Roll (PL 1
3.9)
• Pinch Rollers (PL 1
3.9)
• Exit Roll (PL 13.9)
• Drive Belt (PL 13
.10)
Check the Drive Belt Tension Roll for proper tension.
Enter d
C330 011-142 Vertical Transport In Sensor. Manually act
uate the V-Tra In Sensor
actuator. The display changes from L to H to L as the actuator moves in and out of the
sensor
.
YN
The display is always H
YN
Go to F
lag 1 on BS
D 11.4. Check the harness for a short circuit to ground. If the har-
ness is good, replace the V-Tra In Sensor (PL 13.9
).
+5 VDC is measured between P/J562
-7 and P/J562-9
YN
CR1 on the Mail Box Control PWB is on.
YN
Go to the +5 VDC wirenet and troubleshoot the wires between P/
J5
69-1 and P/
J44-6 on the Distribution PWB.
Replace the Mail Box Control PWB (PL 13.10).
Go t
o Flag 1 and Flag 3 on BS
D11.4. Check the harness for an open circuit. If the harness
is good, replace the V-Tra In Sensor (PL 13.9).
With paper at the sensor, less than +0.5 VDC is measured between P/J562-8 and
GND.
YN
Replace the V-Tra In Sensor (PL 13.
9).
Check t
he following parts for wear, glazing, or slipping.
• Entrance Roll (PL 13.9)
•
Pinch Rollers (PL 13.9
)
•Exit Roll (PL 13.9)
•
Drive Belt (PL 1
3.10)
Check the Drive Belt Tension Roll for proper tension.
A
A
AB C D E
