Xerox DocuColor 12/DCCS50

1/05
6-46
DocuColor 12/DCCS50
dC131 PH NVM List (760)
Reissue
General Procedures
760-019 TRAY 2 STATE 0 None Saves the Tray 2 status.
0=Tray dislocation
1=Tray lifter down (e.g. Insertion)
2=Tray lifter up
3=Tray lifter up - interrupted
4=Tray lifter up (READY)
5=Fault
6=Last P-OFF - Tray dislocation
7=Last P-OFF - Lifter down
8=Last P-OFF - Lifter up
9=Last P-OFF - Lifter up inter-
rupted
10=Last P-OFF - Lifter up
11=Last P-OFF - Fault
Other=Unknown
760-020 TRAY 3 STATE 0 None Saves the Tray 3 status.
0 =Tray dislocation
1=Tray lifter down (e.g. Insertion)
2=Tray lifter up
3=Tray lifter up - interrupted
4=Tray lifter up (READY)
5=Fault
6=Last P-OFF - Tray dislocation
7=Last P-OFF - Lifter down
8=Last P-OFF - Lifter up
9=Last P-OFF - Lifter up inter-
rupted
10=Last P-OFF - Lifter up
11=Last P-OFF - Fault
Other=Unknown
Table 1 PH NVM List (760)
Ch
ain-
Lin
k Name Default Range Description
760-021 TRAY 4 STATE 0 None Saves the Tray 4 status.
0=Tray dislocation
1=Tray lifter down (e.g. Insertion)
2=Tray lifter up
3=Tray lifter up - interrupted
4=Tray lifter up (READY)
5=Fault
6=Last P-OFF - Tray dislocation
7=Last P-OFF - Lifter down
8=Last P-OFF - Lifter up
9=Last P-OFF - Lifter up inter-
rupted
10=Last P-OFF - Lifter up
11=Last P-OFF - Fault
Other=Unknown
Table 1 PH NVM List (760)
Ch
ain-
Lin
k Name Default Range Description
