Xerox DocuColor 12/DCCS50 User Manual

1/05
6-67
DocuColor 12/DCCS50
dC131PH NVM List (761)
General Procedures
Reissue
761-247 ARRIVE AT REGI
SENSOR 7(USED
TRAY 3)
0 None #3 Tray: Measurement result - Registra-
tion Sensor ON timing after Feed start.
Theoretical value=807ms
JAM TIMER=756-856ms (50PPM,
12.
5PPM
B side), 736-876ms
(Other)
Unit=0.5ms/step (Normal paper),
0.
8458ms/
step (This paper 1)
Last storage location - see 761-365.
761-248 ARRIVE AT REGI
SENS
OR 8(USED
TRAY 3)
0 None #3 Tray: Measurement result - Registra-
tion Sensor ON timing after Feed start.
Theoretical value=807ms
JAM TIMER=756-856ms (50PPM,
12.
5PPM
B side), 736-876ms
(Other)
Unit=0.5ms/step (Normal paper),
0.
8458ms/
step (This paper 1)
Last storage location - see 761-365.
761-249 ARRIVE AT REGI
SENS
OR 9(USED
TRAY 3)A
0 None #3 Tray: Measurement result - Registra-
tion Sensor ON timing after Feed start.
Theoretical value=807ms
JAM TIMER=756-856ms (50PPM,
12.
5PPM
B side), 736-876ms
(Other)
Unit=0.5ms/step (Normal paper),
0.
8458ms/
step (This paper 1)
Last storage location - see 761-365.
761-250 ARRIVE AT REGI
SENS
OR 10(USED
TRAY 3)
0 None #3 Tray: Measurement result - Registra-
tion Sensor ON timing after Feed start.
Theoretical value=807ms
JAM TIMER=756-856ms (50PPM,
12.
5PPM
B side), 736-876ms
(Other)
Unit=0.5ms/step (Normal paper),
0.
8458ms/
step (This paper 1)
Last storage location - see 761-365.
Table 1 PH NVM List (761)
Chain-
Link Name Default Range Description
761-251 ARRIVE AT REGI
SENSOR 1(USED
TRAY 4)
0 None #4 Tray: Measurement result - Registra-
tion Sensor ON timing after Feed start.
Theoretical value=1007ms
AM TIMER=956-1056ms (50PPM,
12.
5PPM B
side), 936-1076ms
(Other)
Unit=0.5ms/step (Normal paper),
0.
8458ms/
step (This paper 1)
Last storage location - see 761-366.
761-252 ARRIVE AT REGI
SENSOR
2(USED
TRAY 4)
0 None #4 Tray: Measurement result - Registra-
tion Sensor ON timing after Feed start.
Theoretical value=1007ms
AM TIMER=956-1056ms (50PPM,
12.
5PPM B
side), 936-1076ms
(Other)
Unit=0.5ms/step (Normal paper),
0.
8458ms/
step (This paper 1)
Last storage location - see 761-366.
761-253 ARRIVE AT REGI
SENSOR
3(USED
TRAY 4)
0 None #4 Tray: Measurement result - Registra-
tion Sensor ON timing after Feed start.
Theoretical value=1007ms
AM TIMER=956-1056ms (50PPM,
12.
5PPM B
side), 936-1076ms
(Other)
Unit=0.5ms/step (Normal paper),
0.
8458ms/
step (This paper 1)
Last storage location - see 761-366.
761-254 ARRIVE AT REGI
SENSOR
4(USED
TRAY 4)
0 None #4 Tray: Measurement result - Registra-
tion Sensor ON timing after Feed start.
Theoretical value=1007ms
AM TIMER=956-1056ms (50PPM,
12.
5PPM B
side), 936-1076ms
(Other)
Unit=0.5ms/step (Normal paper),
0.
8458ms/
step (This paper 1)
Last storage location - see 761-366.
Table 1 PH NVM List (761)
Chain-
Link Name Default Range Description
