1/05

7-8

DocuColor 12/DCCS50

Plug/Jack Index

Reissue

Wiring Data

J703B 7.2.17 Tray 5 3

P703B 7.2.17 Tray 5 5

P/J704 7.2.2 Front Upper 4

P/J710 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 9

P/J711 7.2.20 Rear Upper 38

P/J712 7.2.2 Front Upper 7

P/J713 7.2.20 Rear Upper 24

P/J714 7.2.2 Front Upper 3

P/J715 7.2.15 Tray Feeder 12

P/J716 7.2.9 Drawer 1

P/J717 7.2.20 Rear Upper 27

P/J718 7.2.10 Registration 6

P/J719 7.2.10 Registration 5

P/J720 7.2.14 Tray 1-4 Sensor 3

P/J722 7.2.9 Drawer 8

P/J723 7.2.2 Front Upper 13

P/J724 7.2.21 AC Drive PWB/Tray PWB/SSR 7

P/J725 7.2.20 Rear Upper 34

P/J726 7.2.20 Rear Upper 33

P/J728 7.2.16 Inverter Unit 9

P/J729 7.2.16 Inverter Unit 8

P/J730 7.2.16 Inverter Unit 4

P/J731 7.2.20 Rear Upper 17

P/J732 7.2.20 Rear Upper 16

P/J734 7.2.13 Fuser Unit (Rear) 7

J765 7.2.26 DADF-1 3

P769 7.2.26 DADF-1 3

P/J791 7.2.15 Tray Feeder 18

P/J792 7.2.15 Tray Feeder 11

P/J793 7.2.15 Tray Feeder 8

P/J794 7.2.15 Tray Feeder 9

P/J795 7.2.24 Tray 2-4 Take Away Drive/Transformer 5

P/J796 7.2.15 Tray Feeder 10

P799 7.2.21 AC Drive PWB/Tray PWB/SSR 9

P/J800 7.2.21 AC Drive PWB/Tray PWB/SSR 2

P/J801A 7.2.21 AC Drive PWB/Tray PWB/SSR 26

P/J801B 7.2.21 AC Drive PWB/Tray PWB/SSR 26

P/J802A 7.2.21 AC Drive PWB/Tray PWB/SSR 23

P/J802B 7.2.21 AC Drive PWB/Tray PWB/SSR 23

P/J803 7.2.28 Mail Box Sorter 25

P/J803A 7.2.21 AC Drive PWB/Tray PWB/SSR 25

Table 1 Plug/Jack Index connector list

/J No

. Illustration No. Item No.

P/J803B 7.2.21 AC Drive PWB/Tray PWB/SSR 25

P/J804 7.2.21 AC Drive PWB/Tray PWB/SSR 22

P/J805 7.2.21 AC Drive PWB/Tray PWB/SSR 3

P/J805 7.2.28 Mail Box Sorter 21

P/J806 7.2.28 Mail Box Sorter 22

P/J807 7.2.28 Mail Box Sorter 24

P/J818 7.2.28 Mail Box Sorter 30

P/J819 7.2.28 Mail Box Sorter 3

P/J823 7.2.28 Mail Box Sorter 4

P/J880 7.2.28 Mail Box Sorter 19

P/J880A 7.2.28 Mail Box Sorter 19

J880 7.2.21 AC Drive PWB/Tray PWB/SSR 24

J880A 7.2.21 AC Drive PWB/Tray PWB/SSR 24

P880 7.2.28 Mail Box Sorter 15

J880B 7.2.21 AC Drive PWB/Tray PWB/SSR 24

P880B 7.2.28 15

P/J892 7.2.20 Rear Upper 14

P899 7.2.25 B3H LVPS/SSR/Transformer (AP) 5

J900 7.2.21 AC Drive PWB/Tray PWB/SSR 16

P903 7.2.20 Rear Upper 12

P905 7.2.20 Rear Upper 13

P906 7.2.21 AC Drive PWB/Tray PWB/SSR 11

P/J1100 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 7

P/J1150 7.2.20 Rear Upper 28

P/J2010 7.2.20 Rear Upper 6

P/J2020 7.2.20 Rear Upper 25

P/J2030 7.2.20 Rear Upper 8

CN1 7.2.1 Control Panel 3

CN2 7.2.1 Control Panel 15

CN3 7.2.1 Control Panel 6

CN5 7.2.1 Control Panel 1

CN6 7.2.1 Control Panel 2

DP J2 7.2.19 IOT Driver PWB/IOT CPU PWB 3

DS J2 7.2.19 IOT Driver PWB/IOT CPU PWB 2

F51 7.2.12 Fuser Unit (Front) 23

F52 7.2.12 Fuser Unit (Front) 22

F53 7.2.12 Fuser Unit (Front) 2

F54 7.2.12 Fuser Unit (Front) 3

F55 7.2.12 Fuser Unit (Front) 4

F56 7.2.12 Fuser Unit (Front) 5

FS1 7.2.2 Front Upper 8

Table 1 Plug/Jack Index connector list

/J No

. Illustration No. Item No.
