1/05
8d-44
DocuColor 12/DCCS50
12-251 , 12-253
Reissue
Finisher/Sorter
Replace the Eject Paddle Home Sensor (PL 18.19). If the problem continues,
replace the Finisher PWB (PL 18.4).
Disconnect P/J10
55. The display is High.
YN
Go to Fl
ag 6 on
BSD12.14. Check the wire for a short circuit to GND. If the wire is
good, replace the Finisher PWB (PL 18.4)
Replace the Eject Paddle Home Sensor (PL 18
.19).
Check the actuator for the Eject Paddle Home Sensor for binding as it moves in and out of the
sensor.
Ensure that the actuator is secured to the shaft.
Go to Fl
ag 5 and Fl
ag 6 on BSD 12.14. Check for an intermittent short circuit or loose connec-
tions. If the problem continues, replace the Eject
Paddle Home Sensor (PL 18.19).
12-253 RAP
When one of the following occur:
• The Tamper Home Sensor detects that the Tamper remained in the Home position
800msec aft
er Tamper Motor On.
• The Tamper is not detected in the Home position aft
er the Tamper cycle is complete.
Initial Actions
NOTE: It is much easier to access the Tamper components if the Stacker Assembly is
removed. Refer to REP 15.2.2 for this procedure.
Refer to BSD 12.1 and 12.11 for the following procedure.
Procedure
CAUTION
Do not continue to press the Star
t button after the Tamper reaches either the fully-forward or
fully-rearward position.
Push the Tamper towards the rear of the Finisher. Enter dC330 012-060 Tamper Motor Low
Front
. Press Start. The Tamper moves toward the front each time the Start button is
pressed.
YN
T
here is 24 VDC from P/
J1087-
3 to GND and from P/J1087-6 to GND.
YN
Go to F
lag 6 on BS
D 12.11. Check for an open circuit.
Go to Flag 5 on BSD 12.11. Check for an open circuit or a short circuit to GND. If the wires
are good,
Replace the Tamper Motor (PL 18.16). If the problem continues, replace The
Finisher PWB (PL 18.4).
Enter dC330 012-062 Tamper Motor Low Rear. Press St
art. T
he Tamper moves toward the
rear each time the Start button is pressed.
YN
Go to F
lag 5 on BSD 12.11. Check for an open circuit or a short circuit to GND. If the wires
are good,
Replace the Tamper Motor (PL 18.16). If the problem continues, replace The
Finisher PWB (PL 18.4).
Enter dC330 012-061 Tamper Motor Top Front. Press Start. T
he Tamper moves toward the
front each time the Start button is pressed.
YN
Go to F
lag 5 on BSD 12.11. Check for an open circuit or a short circuit to GND. If the wires
are good,
Replace the Tamper Motor (PL 18.16). If the problem continues, replace The
Finisher PWB (PL 18.4).
Enter dC330 012-063 Tamper Motor Top Rear. Press St
ar
t. The Tamper moves toward the
rear approximately 30-50 mm each time the Start button is pressed.
YN
Go to F
lag 5 on BSD 12.11. Check for an open circuit or a short circuit to GND. If the wires
are good,
Replace the Tamper Motor (PL 18.16). If the problem continues, replace The
Finisher PWB (PL 18.4).
A B C
