DocuColor 12/DCCS50
12-265, 12-266
Reissue
Finisher/Sorter
YN
+5 VDC is measured from P/J1037-2 to P/
J1037-3.
YN
+5 VDC is measured from P/
J1026-3 to P/
J1026-2.
YN
Go to F
lag 17 on BS
D 12.1. Check the +5VDC wiring for an open cir-
cuit.
Replace the Finisher PWB (PL 18.4).
Go to Flag 3 and Fla
g 7 on 12.14. Check the harness for an open circuit.
There is +5 VDC from J1054-2 to J1054-3.
YN
Go to Fl
ag 4 on BS
D 12.14. Check the harness for an open circuit. If the wire is
good, replace the Finisher PWB (PL 18.4)
Replace the Eject Clamp Sensor (PL 18.19). I
f the problem continues, replace the
Finisher PWB (PL 18.4).
Disconnect P/J10
54. The display is High.
YN
Go to Fl
ag 4 on BSD
12.14. Check the wire for a short circuit to GND. If the wire is
good, replace the Finisher PWB (PL 18.4)
Replace the Eject Clamp Sensor (PL 18
.19).
The problem appears to be intermittent. Go to Flag
3, Flag 4, Flag 10, and Flag 11 on BSD
12.14. Check the circuits of the Eject Clamp/Offset Motor (PL 18.21) and the Eject Clamp Sen-
sor (PL
18.19) fo
r a loose connection or an intermittent short circuit to GND.
12-266 RAP
The Compiler Cover Safety Switch is closed within 60msec since the completion of Eject Roll
Up.
Initial Actions
Refer to BSD 12.1 and BSD 12.2 for the following procedure.
Ensure that the Compiler Cover Moves freely.
Procedure
Enter dC330 012-306 Compiler Cover Safety Sw. Press Start. The display is Low.
YN
Remove the Stapler Cover Assembly. The actuator on the Compiler cover presses
d
ow
n on the metal leaf of the Compiler Safety Switch.
YN
There is 24 VDC from J1099-2 to GND.
YN
Replace the Finisher PWB (PL 18.
4).
Disconnect P/J1099. T
here is 24 VDC from J1099-2 to GND.
YN
Replace the Compiler Cover Safety Switch (PL 18.
15).
Go to Flag 1 and Fl
ag 2 on BSD 12.2. Check for a short circuit between the two
wires. If the wires are OK, replace the Finisher PWB (PL 18.4).
Check for damage or incorrect installation of the Compiler Cover (REP 15
.2.22). Ensure
that the metal leaf of the Compiler Cover Safety Switch (PL 18.15) is not bent.
The problem may be intermittent. Go to Flag 1
and Flag 2 on BSD 12.2. Check the circuit for
loose connections. Ensure that the Compiler cover is correctly installed. If the problem per-
sists replace the Compiler Cover Safety Switch (PL 18.
15).
