Xerox DocuColor 12/DCCS50 User Manual

1/05
8d-51
DocuColor 12/DCCS50
12-302, 12-303
Finisher/Sorter
Reissue
12-302 RAP
The Compiler Cover Interlock Switch detects the Compiler Cover open.
Initial Actions
Refer to BSD 12.3 for the following procedure.
Ensure that the Compiler Cover moves freely.
Procedure
Enter dC330012-300 Compiler Cover Intlk Sw. Press Start. Raise and lower the Compiler
Cover. The display changes from Low to High to Low.
YN
The display is always Low.
YN
There is less than 1.0 VDC from P/
J1033-5 to
GND.
YN
Go to F
lag 5 and Flag 6 on BS
D 12.3. Check for an open circuit. If the problem
persists, replace the Compiler Cover Interlock Switch (PL 18.15).
Replace the Finisher PWB (PL 18.4).
Disconnect P/J10
98. Enter dC330 012-300 Compiler Cover Intlk Sw. The display is
High.
YN
Go to Fl
ag 6 on BS
D 12.3. Check for a short circuit to GND. If the wire is good,
replace the Finisher PWB (PL 18.4).
Replace the Compiler Cover Safety Switch (PL 18.15).
Th
e problem may be intermittent. Go to Flag
5 and Flag 6 on BSD 12.3. Check for a loose con-
nection. If the problem persists, replace the Compiler Cover Interlock Switch (PL 18.15).
12-303 RAP
The Compiler Cover was detected in the up position during the period between Eject Roll
Down and Eject Roll Up.
Initial Actions
Refer to BSD 12.2 for this procedure.
Procedure
Enter dC330 012-306 Compiler Cover Safety Sw. Press Start. Press down on the Compiler
cover. The display changes from Low to High.
YN
Remove the Stapler Cover Assembly. The actuator on the Compiler cover presses
d
ow
n on the metal leaf of the Compiler Safety Switch.
YN
There is 24 VDC from J1099-2 to GND.
YN
Replace the Finisher PWB (PL 18.
4).
Disconnect P/J1099. T
here is 24 VDC from J1099-2 to GND.
YN
Replace the Compiler Cover Safety Switch (PL 18.
15).
Go to Flag 1 and Fl
ag 2 on BSD 12.2. Check for an open circuit. If the wires are OK,
replace the Finisher PWB (PL 18.4).
Check for damage or incorrect installation of the Compiler Cover (REP 15
.2.22). Ensure
that the metal leaf of the Compiler Cover Safety Switch (PL 18.15) is not bent.
The problem may be intermittent. Go to Flag 1
and Flag 2 on BSD 12.2. Check the circuit for
loose connections. Ensure that the Compiler cover is correctly installed. If the problem per-
sists replace the Compiler Cover Safety Switch (PL 18.
15).
