Xerox DocuColor 12/DCCS50 User Manual

1/05
3-44
DocuColor 12/DCCS50
IQ 47 ATC Sensor RAP
Reissue
Image Quality
009-038 (ATC_LED): actuates the LED ON/OFF.
009-039 (Opening/closing of the shutter and TC measurement):
Measurement of the TC: NVM 775-982 (This function requires t
hat the desired developer
housing is facing the ATC Sensor. Perform the following steps:
a. Enter sub-system check on the UI and sub-system test on the PWS for machine
diagnostic
s. Select developer unit check.
b. For best observation, remove machine Right Upper Cover PL 11.2.
c. Press Start (if using the UI) or move desired developer
into position. Please note the
ATC Sensor is opposite the development position. (UI diagnostics) Select Black,
results in Yellow at ATC Sensor position. Select Magenta, results in Cyan at ATC
Sensor position. Select Cyan results in Black at ATC Sensor position. Select Yellow,
results in Home position. Select Home, results in Magenta at ATC Sensor position.
d. Close “developer unit check” screen. The desired developer housing remains in
posit
ion.
e.
Enter dC330 Component control. Enter 009-039 and press Start. (Shutter activa-
tion). Close dC330.
f. Enter NVM read \ write. NVM 775-982 = TC reading for desired color. (Black is not
detect
able with ATC Sensors) Value range 140 ~ 200 for selected color.
g. If 775-982 is out of given range, perform steps b) through h) of Appendix 1. If prob-
lem continues refer to “Hardware Repairs”.
9. Check the following NVM and ensure the values are set to given value. Correct values if
needed and repe
at steps b) through g) of Appendix 1
10. dC131 (NVM) after the ATC Sensor is implemented.
11.Check that the following dC131 values have been added according to the ATC Sensor
implem
entat
ion. NVM are noted if values are judgements or result readings to clarify
some NVM are readings and may vary.
Table 3
NVM designation Chain Link SET value
TH2_100_PV_K 773 223 200
K_Delta_VHS_HUM_DWN 773 286 961
K_Delta_VMS_HUM_DWN 773 287 250
K_Delta_BIAS_HUM_DWN 773 289 624
K_Delta_Radc_SET_HUM_K_DWN 773 309 0
TH1_G100(K) 775 664 65
TH2_G100(K) 775 669 60
Delta_RADCS_100_MAX_K 775 673 100
ATC_CTRL_SW 775 731 1
TC_OFFSET_OUT_TH 775 773 200
TC_Ref_OUT_MIN 775 776 200
TC_Ref_OUT_MAX 775 777 600
TC_OUT_Adj_MAX 775 779 350
TC_Ref 775 783 420
TC_SET[Y] 775 784 173
TC_SET[M] 775 785 173
TC_SET[C] 775 786 175
TC_OUT_Hilimit1[Y] 775 821 30
TC_OUT_Hilimit1[M] 775 822 30
TC_OUT_Hilimit1[C] 775 823 30
TC_OUT_Hilimit2[Y] 775 825 15
TC_OUT_Hilimit2[M] 775 826 15
TC_OUT_Hilimit2[C] 775 827 15
TC_OUT_Lolimit1[Y] 775 829 20
TC_OUT_Lolimit1[M] 775 830 20
TC_OUT_Lolimit1[C] 775 831 20
TC_CNT_Hi2_MAX 775 839 8
TC_CNT_Lo2_MAX 775 840 8
TC_CYAN_OFFSET 775 850 494
TC_RADCS_UP_STEP2 775 859 10
TC_RADCS_DWN_STEP2 775 860 8
Delta_RADCS_TC_MAX[Y] 775 874 592
Delta_RADCS_TC_MAX[M] 775 875 592
Delta_RADCS_TC_MAX[C] 775 876 592
TC_PV_INT 775 896 4
Radc_SET_Adj_MIN[K] 775 914 100
Radc_SET_DISP_Adj_MIN[K] 775 924 100
TC_SET_OUT_MAX[Y] 775 966 300
TC_SET_OUT_MAX[M] 775 967 300
TC_SET_OUT_MAX[C] 775 968 300
TC_SET_INIT 775 991 205
Table 4
Chain-Link
No
.
NVM
Designation
Initial
Value Set Range Meaning
775-731 ATC_CTRL_SW 1 0~65535 ATC Control Switch 1=ON,
0=O
FF
775-736 T
C_Flag1 0 0~65535 Calibration Control of the
ATC S
ensor for M/C to M/C
variation
1: Execution of the TRC CON
+ Diag.
0: TRC CONT + MINISET by
AT
C
Tab
le 3
NVM
desi
gnation Chain Link SET value
