DocuColor 12/DCCS50
REP 6.7.1
Repairs and Adjustments
Reissue
Figure 2 Remove the Outer Dispense Cover
5. Remove the cover (Figure 3
).
1.Remove the screws (4).
2. Remove the cover.
Figure 3 Remove the Cover
6. Remove the Inner/Outer DIspense Housings (F
igure 4).
1. Remove the E-clip.
2. Remove the bearing (plastic).
3. Remove the Inner/Outer Dispense Housings.
