Xerox DocuColor 12/DCCS50

1/05
6-97
DocuColor 12/DCCS50
dC301 NVM Initialization
General Procedures
Reissue
• 775-852 ADC change by ATC (M)
• 775-853 ADC change by ATC (C)
7. Go to dC131 NVM
R/W:
• Record the value in location 990-302 (v7.06.
3 software only)
• Record the value in location 759-039 (v7
.06.3 software only)
• If IOT software v11.50.3 is loaded, set NVM location 752-017 to 0.
• If a Foreign Interface was enabled, record the value in NVM location 759-015, then
set locati
on 752-002 to 0.
CAUTION
DO NOT use the Select All
button to perform a complete NVM Initialization! If a full initializa-
tion is indicated, reset each area one-at-a-time, in the following sequence:
•IISS
•POST IPS
•IOSS
•Sys
•UI
• Sys (again)
8. Select d
C301 NV
M Initialize.
9. Select the appropriate area(s) to be initialized. Table 1 list
s the NVM locations that are ini-
tialized with each area selection.
10. After all initializations are complete, go to d
C131 NVM
R/W. Re-enter the values for those
locations (759-015, 759-039, and/or 990-302) that were saved in step 7.
11. If NVM was successfully saved in step 5,
go to dC351 and select Restore Machine Set-
tings. If NVM was not successfully saved, use the date a from step 2
and step 6 to man-
ually restore NVM.
12. Re-enter the values in the following tables even if the display indicates that the values are
already correct.
T
able 1 NVM Initialization
Name Description Remarks
IISS (PreIPS) The following NVM will be initial-
ized.
a. IIT NVM: Chain710 (All)
b. IIT NVM: Chain715 (All)
c. IIT NVM: Chain719 (All)
Default: See dC131.
a.
POST IPS The following NVM will be initial-
ized.
a. IPS NVM:Chain730-001-169
Default: See dC131.
a.
IOT (IOSS) The following NVM will be initial-
ized.
a. ROS NVM: Chain720 (All)
b. PH NVM: Chain740, 749,
760,
761 (All)
c. Mar
king NVM: Chain770 (All
except 087-100)
d.
IBT NVM: Chain771 (All)
e. Drive NVM: Chain772 (All)
f. Procon NVM: Chain773,
774, 775,
779 (All)
g. Deve NVM: Chain776 (All)
h. Fuser NVM: Chain777 (All)
i. SorterNVM: Chain780 (All)
j. Billing NVM: Chain990: 037,
293, 294,
295, 296, 297,
298, 299, 300, 301, 302
Default: See dC131.
a.
SYS
a. SYS NVM: Chain752 (All
exce
pt t
he following codes)
(752-001-016)
b. SYS NVM: Chain759 (All
except t
he following codes)
(759-130-150)
Default: See dC131.
a.
UI The following NVM will be initial-
ized:
a. UI NVM: Chain700 (All)
b. UI NVM: Chain702 (All)
c. UI NVM: Chain850 (1-006)
Default: See dC131. Chain802 is
not
initiali
zed.
a.
Table 1 NVM Initialization
Name
Descrip
tion Remarks
