Xerox DocuColor 12/DCCS50 User Manual

1/05
7-4
DocuColor 12/DCCS50
Plug/Jack Index
Reissue
Wiring Data
P/J59 7.2.23 Power Chassis 1
P/J70 7.2.30 w/Tag P31 (ESG only) 3
J71 7.2.30 w/Tag P31 (ESG only) 6
J72 7.2.30 w/Tag P31 (ESG only) 5
J73 7.2.30 w/Tag P31 (ESG only) 8
J74 7.2.30 w/Tag P31 (ESG only) 7
P/J76 7.2.30 w/Tag P31 (ESG only)
P/J81 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 19
P/J81 7.2.25 B3H LVPS/SSR/Transformer (AP) 7
P/J82 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 14
P/J82 7.2.25 B3H LVPS/SSR/Transformer (AP) 8
P/J83 7.2.25 B3H LVPS/SSR/Transformer (AP) 10
P/J84 7.2.10 Registration 8
P/J84 7.2.25 9
P/J91 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 18
P/J92 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 15
P/J93 7.2.8 IBT 3
P/J95 7.2.20 Rear Upper 23
P/J96 7.2.10 Registration 7
P/J98 7.2.24 Tray 2-4 Take Away Drive/Transformer 1
P/J98 7.2.25 B3H LVPS/SSR/Transformer (AP) 4
P/J99 7.2.25 B3H LVPS/SSR/Transformer (AP) 7
P/J99 7.2.24 Tray 2-4 Take Away Drive/Transformer 6
P/J100 7.2.21 AC Drive PWB/Tray PWB/SSR 13
P/J101A 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 1
P/J101B 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 6
P/J101C 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 3
P/J101D 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 4
P/J101E 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 5
P/J101F 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 2
P/J105 7.2.21 AC Drive PWB/Tray PWB/SSR 14
P/J109 7.2.17 Tray 5 13
P/J110 7.2.20 Rear Upper 3
P/J111 7.2.8 IBT 5
P/J112 7.2.20 Rear Upper 11
P/J113 7.2.2 Front Upper 2
P/J114 7.2.2 Front Upper 1
P/J115 7.2.20 Rear Upper 29
P/J116 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 8
P/J117 7.2.5 Toner Cartridge 13
P/J118 7.2.5 Toner Cartridge 14
Table 1 Plug/Jack Index connector list
P
/J No
. Illustration No. Item No.
P/J119 7.2.5 Toner Cartridge 15
P/J120 7.2.5 Toner Cartridge 16
P/J121 7.2.15 Tray Feeder 16
P/J122 7.2.2 Front Upper 15
P/J123 7.2.15 Tray Feeder 15
P/J124 7.2.15 Tray Feeder 14
P/J125 7.2.15 Tray Feeder 13
P/J127 7.2.15 Tray Feeder 17
P/J128 7.2.15 Tray Feeder 4
P/J129 7.2.15 Tray Feeder 3
P/J130 7.2.15 Tray Feeder 2
P/J131 7.2.14 Tray 1-4 Sensor 4
P/J132 7.2.14 Tray 1-4 Sensor 5
P/J134 7.2.14 Tray 1-4 Sensor 6
P/J136 7.2.14 Tray 1-4 Sensor 7
P/J139 7.2.8 IBT 1
P/J140 7.2.8 IBT 2
P/J141 7.2.2 Front Upper 10
P/J142 7.2.2 Front Upper 16
P/J144 7.2.17 Tray 5 8
P/J145 7.2.17 Tray 5 10
P/J146 7.2.17 Tray 5 9
P/J147 7.2.17 Tray 5 7
P/J148 7.2.17 Tray 5 11
P/J149 7.2.16 Inverter Unit 6
P/J150 7.2.16 Inverter Unit 2
P/J151 7.2.16 Inverter Unit 3
P/J152 7.2.16 Inverter Unit 10
P/J153 7.2.9 Drawer 2
P/J154 7.2.9 Drawer 7
P/J157 7.2.11 2nd BTR 2
P/J158 7.2.11 2nd BTR 1
P/J159 7.2.9 Drawer 3
P/J160 7.2.10 Registration 3
P/J161 7.2.10 Registration 1
P/J162 7.2.10 Registration 2
P/J163 7.2.10 Registration 4
P/J164 7.2.16 Inverter Unit 5
P/J167 7.2.12 Fuser Unit (Front) 16
P/J168 7.2.12 Fuser Unit (Front) 1
P/J169 7.2.13 Fuser Unit (Rear) 6
Table 1 Plug/Jack Index connector list
P
/J No
. Illustration No. Item No.
