1/05
7-5
DocuColor 12/DCCS50
Plug/Jack Index
Wiring Data
Reissue
P/J170 7.2.12 Fuser Unit (Front) 7
P/J171 7.2.12 Fuser Unit (Front) 20
P/J172 7.2.12 Fuser Unit (Front) 21
P/J173 7.2.12 Fuser Unit (Front) 15
P/J174 7.2.12 Fuser Unit (Front) 17
P/J175 7.2.12 Fuser Unit (Front) 19
P/J176 7.2.12 Fuser Unit (Front) 13
P/J191 7.2.13 Fuser Unit (Rear) 2
P/J192 7.2.13 Fuser Unit (Rear) 5
P/J193 7.2.13 Fuser Unit (Rear) 3
P/J194 7.2.12 Fuser Unit (Front) 12
P/J195 7.2.12 Fuser Unit (Front) 14
P/J196 7.2.12 Fuser Unit (Front) 11
P/J198 7.2.13 Fuser Unit (Rear) 4
P/J199 7.2.12 Fuser Unit (Front) 18
P/J201 7.2.20 Rear Upper 7
P/J202 7.2.20 Rear Upper 26
P/J203 7.2.20 Rear Upper 5
P/J204 7.2.20 Rear Upper 32
P/J209A 7.2.5 Toner Cartridge 11
P/J209B 7.2.5 Toner Cartridge 12
P/J210A 7.2.5 Toner Cartridge 9
P/J210B 7.2.5 Toner Cartridge 10
P/J211A 7.2.5 Toner Cartridge 7
P/J211B 7.2.5 Toner Cartridge 8
P/J212A 7.2.5 Toner Cartridge 5
P/J212B 7.2.5 Toner Cartridge 6
P/J213 7.2.5 Toner Cartridge 1
P/J214 7.2.5 Toner Cartridge 2
P/J215 7.2.5 Toner Cartridge 3
P/J216 7.2.5 Toner Cartridge 4
P/J217 7.2.24 Tray 2-4 Take Away Drive/Transformer 2
P/J218 7.2.10 Registration 9
P/J220 7.2.9 Drawer 9
P/J222 7.2.20 Rear Upper 18
P/J223 7.2.17 Tray 5 12
P/J224 7.2.15 Tray Feeder 5
P/J233 7.2.12 Fuser Unit (Front) 8
P/J251 7.2.20 Rear Upper 4
P/J252 7.2.20 Rear Upper 30
P/J253 7.2.21 AC Drive PWB/Tray PWB/SSR 1
Table 1 Plug/Jack Index connector list
P
/J No
. Illustration No. Item No.
P/J254 7.2.17 Tray 5 6
P/J255 7.2.20 Rear Upper 15
P/J256 7.2.20 Rear Upper 19
P/J257 7.2.20 Rear Upper 10
P/J260 7.2.20 Rear Upper 2
P/J261 7.2.20 Rear Upper 1
P/J262 7.2.20 Rear Upper 36
P/J264 7.2.24 Tray 2-4 Take Away Drive/Transformer 3
P/J266 7.2.24 Tray 2-4 Take Away Drive/Transformer 4
P/J268 7.2.24 Tray 2-4 Take Away Drive/Transformer 6
P/J272 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 12
P/J273 7.2.16 Inverter Unit 7
P/J274 7.2.16 Inverter Unit 1
P/J275 7.2.17 Tray 5 1
P/J276 7.2.15 Tray Feeder 1
P/J280 7.2.21 AC Drive PWB/Tray PWB/SSR 21
P/J281 7.2.20 Rear Upper 35
P/J282 7.2.19 IOT Driver PWB/IOT CPU PWB 15
P/J283 7.2.2 Front Upper 11
P/J284 7.2.2 Front Upper 12
P/J289 7.2.2 Front Upper 14
P/J341 7.2.6 ROS/Half Tone PWB 3
P/J342 7.2.6 ROS/Half Tone PWB 1
P/J345 7.2.6 ROS/Half Tone PWB 4
P/J347 7.2.6 ROS/Half Tone PWB 2
J387 7.2.7 VSEL Base TTL PWB (AP) 6
P387 7.2.6 ROS/Half Tone PWB 10
P/J388 7.2.19 IOT Driver PWB/IOT CPU PWB 1
P/J389 7.2.7 VSEL Base TTL PWB (AP) 2
P/J391 7.2.7 VSEL Base TTL PWB (AP) 7
J393 7.2.7 VSEL Base TTL PWB (AP) 5
P393 7.2.6 ROS/Half Tone PWB 8
P/J395 7.2.6 ROS/Half Tone PWB 9
J396 7.2.18 Main Switch/Deve.Bias HVPS/CC/PDD HVPS 17
P396 7.2.6 ROS/Half Tone PWB 7
P/J397 7.2.6 ROS/Half Tone PWB 6
P/J398 7.2.6 ROS/Half Tone PWB 5
P/J399 7.2.6 ROS/Half Tone PWB 11
P/J400 7.2.19 IOT Driver PWB/IOT CPU PWB 20
P401 7.2.19 IOT Driver PWB/IOT CPU PWB 21
P402 7.2.19 IOT Driver PWB/IOT CPU PWB 22
Table 1 Plug/Jack Index connector list
P
/J No
. Illustration No. Item No.
