1/05
7-6
DocuColor 12/DCCS50
Plug/Jack Index
Reissue
Wiring Data
P/J403 7.2.19 IOT Driver PWB/IOT CPU PWB 4
P/J404 7.2.19 IOT Driver PWB/IOT CPU PWB 6
P/J405 7.2.19 IOT Driver PWB/IOT CPU PWB 23
P/J406 7.2.19 IOT Driver PWB/IOT CPU PWB 5
P/J411 7.2.19 IOT Driver PWB/IOT CPU PWB 12
P/J412A 7.2.19 IOT Driver PWB/IOT CPU PWB 16
P/J412B 7.2.19 IOT Driver PWB/IOT CPU PWB 16
P/J413A 7.2.19 IOT Driver PWB/IOT CPU PWB 9
P/J413B 7.2.19 IOT Driver PWB/IOT CPU PWB 9
P/J414A 7.2.19 IOT Driver PWB/IOT CPU PWB 7
P/J414B 7.2.19 IOT Driver PWB/IOT CPU PWB 7
P/J415A 7.2.19 IOT Driver PWB/IOT CPU PWB 14
P/J415B 7.2.19 IOT Driver PWB/IOT CPU PWB 14
P/J416A 7.2.19 IOT Driver PWB/IOT CPU PWB 11
P/J416B 7.2.19 IOT Driver PWB/IOT CPU PWB 11
P/J417A 7.2.19 IOT Driver PWB/IOT CPU PWB 19
P/J417B 7.2.19 IOT Driver PWB/IOT CPU PWB 19
P/J418A 7.2.19 IOT Driver PWB/IOT CPU PWB 10
P/J418B 7.2.19 IOT Driver PWB/IOT CPU PWB 10
P/J419A 7.2.19 IOT Driver PWB/IOT CPU PWB 8
P/J419B 7.2.19 IOT Driver PWB/IOT CPU PWB 8
P/J420A 7.2.19 IOT Driver PWB/IOT CPU PWB 18
P/J420B 7.2.19 IOT Driver PWB/IOT CPU PWB 18
P/J421A 7.2.19 IOT Driver PWB/IOT CPU PWB 17
P/J421B 7.2.19 IOT Driver PWB/IOT CPU PWB 17
P/J422A 7.2.19 IOT Driver PWB/IOT CPU PWB 13
P/J422B 7.2.19 IOT Driver PWB/IOT CPU PWB 13
P/J431 7.2.5 Toner Cartridge 18
P/J432 7.2.5 Toner Cartridge 17
P/J433A 7.2.5 Toner Cartridge 20
P/J433B 7.2.5 Toner Cartridge 20
P/J434 7.2.5 Toner Cartridge 19
P/J440 7.2.12 Fuser Unit (Front) 10
P/J441 7.2.12 Fuser Unit (Front) 9
P/J482A (
CN1) 7.2.
1 Control Panel 9
P/J482A 7.2.1 Control Panel 10
P/J482B(CN2) 7.2.1 Control Panel 7
P/J482B 7.2.1 Control Panel 11
P/J484 7.2.1 Control Panel 5
P/J486 7.2.1 Control Panel 4
P/J490 7.2.1 Control Panel 12
Table 1 Plug/Jack Index connector list
P
/J No
. Illustration No. Item No.
P491 7.2.1 Control Panel 14
P/J492(CN4) 7.2.1 Control Panel 8
P/J493 7.2.1 Control Panel 13
P/J500 7.2.3 IIT 1
P/J508 7.2.25 B3H LVPS/SSR/Transformer (AP) 3
P/J509 7.2.25 B3H LVPS/SSR/Transformer (AP) 2
P/J510 7.2.4 IPS 1
P512 7.2.4 IPS 8
P/J513 7.2.4 IPS 25
P/J514 7.2.4 IPS 26
P/J515 7.2.4 IPS 18
P516 7.2.4 IPS 21
P/J517 7.2.4 IPS 13
P518 7.2.4 IPS 27
P/J519 7.2.4 IPS 19
P/J520 7.2.3 IIT 10
P/J521 7.2.3 IIT 14
P/J522 7.2.3 IIT 11
P/J523 7.2.3 IIT 13
P/J524 7.2.3 IIT 12
P/J530 7.2.3 IIT 7
P/J531 7.2.3 IIT 6
P/J532 7.2.3 IIT 5
P/J533 7.2.3 IIT 2
P/J534 7.2.3 IIT 9
P/J535 7.2.3 IIT 3
P536 7.2.4 IPS 17
P/J537 7.2.3 IIT 2
P/J540 7.2.3 IIT 18
P/J541 7.2.3 IIT 4
P/J542 7.2.3 IIT 16
J543A 7.2.3 IIT 17
J543B 7.2.3 IIT 17
P543A 7.2.26 DADF-1 10
P543B 7.2.26 DADF-1 10
P/J544 7.2.3 IIT 15
P/J550 7.2.27 DADF-2 5
P/J550 7.2.28 Mail Box Sorter 26
P/J551 7.2.27 DADF-2 4
P/J551 7.2.28 Mail Box Sorter 6
P/J552 7.2.28 Mail Box Sorter 7
Table 1 Plug/Jack Index connector list
P
/J No
. Illustration No. Item No.
