Xerox DocuColor 12/DCCS50 User Manual

1/05
9-28
DocuColor 12/DCCS50
Convenience Stapler Installation
Reissue
Installation Instructions
Figure 7 Align the Bracket
8. 1. Slip the mounting bracket up and behind the platen surround (Figur
e 8).
2. Ensure that the holes on the bracket align with the holes on the left side of the proces-
sor.
Figure 8 Install the Bracket
9. Secure the bracket using seven 5.5 mm M3 screws (Figure 9).
