Xerox DocuColor 12/DCCS50

1/05
6-102
DocuColor 12/DCCS50
dC330 Component Control
Reissue
General Procedures
008-241 #2 TRAY SIZE S/W 2 Input High: Switch on (soft data)
Cannot run with Tray 3 size switch
1,2,3,
4
Cannot run with Tray 4 size switch
1,
2,3,
4
Processor
008-242 #2 TRAY SIZE S/W3 Input High: Switch on (soft data)
Cannot run with Tray 3 size switch
1,
2,3,
4
Cannot run with Tray 4 size switch
1,
2,3,
4
Processor
008-243 #2 TRAY SIZE S/W4 Input High: Switch on (soft data)
Cannot run with Tray 3 size switch
1,
2,3,
4
Cannot run with Tray 4 size switch
1,
2,3,
4
Processor
008-245 #3 TRAY SIZE S/W1 Input High: Switch on (Soft data)
Cannot run with Tray 2 size switch
1,
2,3,
4
Cannot run with Tray 4 size switch
1,
2,3,
4
Processor
008-246 #3 TRAY SIZE S/W2 Input High: Switch on (soft data)
Cannot run with Tray 2 size switch
1,
2,3,
4
Cannot run with Tray 4 size switch
1,
2,3,
4
Processor
008-247 #3 TRAY SIZE S/W 3 Input High: Switch on (soft data)
Cannot run with Tray 2 size switch
1,
2,3,
4
Cannot run with Tray 4 size switch
1,
2,3,
4
Processor
008-248 #3 TRAY SIZE S/W 4 Input High: Switch on (Soft data)
Cannot run with Tray 2 size switch
1,
2,3,
4
Cannot run with Tray 4 size switch
1,
2,3,
4
Processor
008-250 #4 TRAY SIZE S/W 1 Input High: Switch on (Soft data)
Cannot run with Tray 2 size switch
1,
2,3,
4
Cannot run with Tray 3 size switch
1,
2,3,
4
Processor
Table 1 Input Component Control Codes
ID
Des
cription In_Out Smart Help
Module_I
D
008-251 #4 TRAY SIZE S/W 2 Input High: Switch on (Soft data)
Cannot run with Tray 2 size switch
1,2,3,
4
Cannot run with Tray 3 size switch
1,
2,3,
4
Processor
008-252 #4 TRAY SIZE S/W 3 Input High: Switch on (Soft data)
Cannot run with Tray 2 size switch
1,
2,3,
4
Cannot run with Tray 3 size switch
1,
2,3,
4
Processor
008-253 #4 TRAY SIZE S/W 4 Input High: Switch on (Soft data)
Cannot run with Tray 2 size switch
1,
2,3,
4
Cannot run with Tray 3 size switch
1,
2,3,
4
Processor
008-305 Tray 5 Interlock Input High: Tray 5 (bypass) feeder open.
Low: Tray 5 feeder closed.
Processor
008-306 DRAWER HANDLE
INTER
LOCK
Input High: Open
Low: Close
Processor
009-215 2ND BELT TRANSFER
ROLL HO
ME POSI-
TION SENSOR
Input High: Light block
Low: Light reception
Processor
009-216 IBT CLEANER
R
ETR
ACT HOME
POSITION
Input High: Home detected Processor
009-217 OIL ROLL RETRACT
HOME
PO
SITION
Input High: Light block
Low: Light reception
Processor
009-220 ROTARY HOME POSI-
TION SENSOR
Input High: Home detected Processor
009-237 ROTARY LOCK MECH
SE
NSO
R
Input High: Latch
Low: Release
Processor
009-245 CRU POSITION Input High: If CRUM (X CRU Type) is cor-
rectly read
Processor
009-246 CRU TYPE Input High: If CRUM (X CRU Type) is cor-
rectly read and NVM (CRU type)
mat
ches.
Processor
009-248 WASTE AUGER
ROT
AT
E SENSOR
Input x Processor
009-249 WASTE BOTTLE POSI-
TION SENSOR
Input High: Set
Low: Not Set
Processor
Table 1 Input Component Control Codes
I
D Descri
ption In_Out Smart Help
Module_I
D
