Xerox DocuColor 12/DCCS50

1/05
6-103
DocuColor 12/DCCS50
dC330 Component Control
General Procedures
Reissue
009-250 WASTE BOTTLE FULL
SENSOR
Input High: Full
Low: Not Full
Processor
009-251 TRICKLE BOTTLE
SENSO
R
Input High: Trickle Bottle Full
Low: Not Full
Processor
009-255 LOW TONER SEN-
SOR K
Input High: Toner
Low: No Toner
Processor
009-257 LOW TONER SEN-
SOR Y
Input High: Toner
Low: No Toner
Processor
009-258 LOW TONER SEN-
SOR M
Input High: Toner
Low: No Toner
Processor
009-259 LOW TONER SEN-
SOR C
Input High: Toner
Low: No Toner
Processor
010-100 FUSER ENTRANCE
SE
NSO
R
Input High: No Paper
Low: Paper
Processor
010-105 FUSER EXIT SENSOR Input High: No Paper
Low: Paper
Processor
010-110 MACHINE EXIT SEN-
SOR
Input High: Paper
Low: No Paper
Processor
010-115 EXIT PATH SENSOR Input High: Paper
Low: No Paper
Processor
010-125 INVERT PATH SEN-
SOR
Input High: Paper
Low: No Paper
Processor
010-130 DUPLEX IN SENSOR Input High: Paper
Low: No Paper
Processor
010-132 DUPLEX PATH 1 SEN-
SOR
Input High: Paper
Low: No Paper
Processor
010-133 DUPLEX OUT SEN-
SOR
Input High: Paper
Low: No Paper
Processor
010-220 PRESSURE ROLL
RE
TR
ACT SENSOR
Input High: Release Position
Low: NIP Position
Processor
010-221 EXTERNAL HEAT
ROLL R
ETRACT SEN-
SOR
Input High: Retract Position
Low: Contract Position
Processor
010-222 OIL SENSOR Input High: Empty
Low: Oil Not Empty
Processor
010-223 WEB CRU HOME Input High: No CRU
Low: CRU
Processor
010-224 IIT HOTLINE Input Normal state is Low Processor
Table 1 Input Component Control Codes
ID
Des
cription In_Out Smart Help
Module_I
D
010-296 OCT DETECT Input High: OCT not connected
Low: OCT connected
Processor
010-297 OCT FULL SENSOR Input High: Empty
Low: Not Empty
Processor
010-298 OCT HOME SENSOR Input High: Home position detected Processor
010-299 OCT POSITION SEN-
SOR
Input High: Offset position detected Processor
010-300 INVERT COVER
INTER
LOCK
Input High: Open
Low: Close
Processor
011-107 OCT EXIT SENSOR Input High: Paper
Low: No Paper
Checks the paper ejection detection
sensor input (O
CT)
Sorter
011-115 MAILBOX VERTICAL
SE
NSO
R
Input High: Paper
Low: No Paper
Checks the paper ejection detection
s
ensor input
Sor
ter
011-117 DECURLER EXIT SEN-
SOR
Input x Sorter
011-142 VERTICAL TRANS-
PORT IN SENSOR
Input High: Paper
Low: No Paper
Checks the paper ejection sensor
input
. (Bin 1-10)
So
rter
011-250 OCT DEVICE DETECT Input x Sorter
011-273 OCT OFFSET HOME
SENSO
R
Input High: Home Sorter
011-274 OCT OFFSET POSI-
TION SENSOR
Input High: Offset
Checks the OCT Offset position
detecti
on sensor input
Sorter
011-275 OCT FULL STACK
SE
NSO
R
Input High: Not Full
Low: Full
Sorter
011-276 DECURLER CAM
POSI
TION SENSOR A
Input Checks the Decurler Cam Position
sensor A input
Sorter
011-277 DECURLER CAM
POSI
TION SENSOR B
Input x Sorter
011-281 BIN 1 FULL SENSOR Input High: Not Full
Low: Full
Checks Bin 1 full detection sensor
stat
us
Sorter
Table 1 Input Component Control Codes
ID Descri
ption In_Out Smart Help
Module_I
D
