Xerox DocuColor 12/DCCS50

1/05
6-106
DocuColor 12/DCCS50
dC330 Component Control
Reissue
General Procedures
Output CC Codes
012-281 BIN 1 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 1 Full Detection SNR
inputt
ing.
Fi
nisher
012-282 BIN 2 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 2 Full Detection SNR
inputting.
Fi
nisher
012-283 BIN 3 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 3 Full Detection SNR
inputt
ing.
Fi
nisher
012-284 BIN 4 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 4 Full Detection SNR
inputt
ing.
Fi
nisher
012-285 BIN 5 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 5 Full Detection SNR
inputting.
Fi
nisher
012-286 BIN 6 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 6 Full Detection SNR
inputt
ing.
Fi
nisher
012-287 BIN 7 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 7 Full Detection SNR
inputt
ing.
Fi
nisher
012-288 BIN 8 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 8 Full Detection SNR
inputting.
Fi
nisher
012-289 BIN 9 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 9 Full Detection SNR
inputt
ing.
Fi
nisher
012-290 BIN 10 FULL SENSOR Input High: Bin not full
Low: Bin full
Checks Bin 10 Full Detection SNR
inputt
ing.
Fi
nisher
012-291 UNLOAD WHITE RUN
SW
IT
CH
Input High: Open
Low: Closed
IOT Feed stop signal.
Finisher
Table 1 Input Component Control Codes
ID
Des
cription In_Out Smart Help
Module_I
D
012-300 COMPILER COVER
INTERLOCK SWITCH
Input High: Open
Low: Closed
Senses Compiler Cover Interlock
O
pen. I
OT Feed stop signal.
Finisher
012-301 MAILBOX DOOR
INTER
LOCK SWITCH
Input High: Open
Low: Closed
Front Cover A Interlock Switch.
Finisher
012-302 DECURLER DOOR
IN
TER
LOCK SWITCH
Input High: Open
Low: Closed
Front Cover B Interlock Switch
Finisher
012-303 DOCKING INTERLOCK
SW
IT
CH
Input High: Docked
Low: Undocked
Senses the docking to Processor.
I
OT
Feed stop signal.
Finisher
012-304 STAPLE DOOR INTER-
LOCK SWITCH
Input High: Open
Low: Closed
Senses Front Cover C Interlock
open.
I
OT Feed Stop signal.
Finisher
012-306 COMPILER COVER
SAFE
TY SWITCH
Input High: Closed
Low: Open
Senses Compiler Upper Chute
open.
IO
T Feed stop signal that
turns off 24V to Staple Motor.
Finisher
014-260 ROS READY Input High: Stop
Low: Regular Rotation
Checks the Polygon Motor
Run Polygon Motor High Speed
(0
14 - 051) simult
aneously
015-200 ITT IMAGE AREA Input Checks IIT image area IIT
Table 2 Output Component Control Codes
ID Description In_Out Smart Help
Module_I
D
003-001 TRD ENABLE Output x Processor
003-002 24 OK Output Turn on (force) the K1 Relay of the
AC
Dr
ive PWBA
Processor
Table 1 Input Component Control Codes
ID Descri
ption In_Out Smart Help
Module_I
D
