1/05
6-109
DocuColor 12/DCCS50
dC330 Component Control
General Procedures
Reissue
009-032 DISPENSE MOTOR Y Output Start after moving the Rotary to the
Y color and dispensing the Toner.
NOTE: To drive the rotary, move the
rot
ary
to the Y color in dC920
(Developer Unit Check)
Automatically turns off after 2 sec.
Cannot run with Dispense Motor M
(009-
033),
C (009-034) or K (009-
031).
Processor
009-033 DISPENSE MOTOR M Output Start after moving the Rotary to the
Y
color
and dispensing the Toner.
NOTE: To drive the rotary, move the
rot
ary
to the Y color in dC920
(Developer Unit Check)
Automatically turns off after 2 sec.
Cannot run with Dispense Motor Y
(009-
032),
C (009-034) or K (009-
031).
Processor
009-034 DISPENSE MOTOR C Output Start after moving the Rotary to the
Y
color
and dispensing the Toner.
NOTE: To drive the rotary, move the
rot
ary
to the Y color in dC920
(Developer Unit Check)
Automatically turns off after 2 sec.
Cannot run with Dispense Motor Y
(009-
032),
C (009-033) or K (009-
031).
Processor
009-040 ADC LED Output On: L Processor
009-050 ERASE LAMP Output On: Turns on the lamp. Processor
009-057 2ND BELT TRANSFER
ROLL
Output Run simultaneously with Drum
M
ot
or (004-021) and 2nd BTR CL
ON - Contact (009-058)
DC ON: 2.2kV - Discharge (can be
ch
anged in NVM
771-033)
Processor
009-058 2ND BELT TRANSFER
ROLL CONT
AC
T
Output Run simultaneously with Drum
Motor (004-007)
Automatically turns off after the 2nd
B
TR Hom
e Position sensor detects
the Contact On Position, On: Low
Cannot run with 2nd BTR CL On -
Ret
ract
(009-059)
Processor
Table 2 Output Component Control Codes
ID Des
cription In_Out Smart Help
Module_I
D
009-059 2ND BELT TRANSFER
ROLL RETRACT
Output Run simultaneously with Drum
Motor (004-021) and Main Motor
(004-007)
Automatically turns off after the 2nd
B
TR
Home Position Sensor detects
the Retract Position, On: Low
Cannot run with 2nd BTR CL On -
Cont
act (
009-058)
Processor
009-066 IBT CLEANER CON-
TACT
Output Run simultaneously with Main
M
otor
(004-007)
Automatically turns off after the IBT
Cleaner
Contact
Home Position
Sensor detects the contact position.
ON: Low, OFF: High
Processor
009-067 IBT CLEANER
RE
TRA
CT
Output Run simultaneously with Main
Motor (004-007)
Automatically turns off after the IBT
Cleaner
Contact
Home Position
Sensor detects the contact position.
Cannot run with IBT Cleaner Con-
tact (009-066).
Processor
009-068 PRE CLEAN
COROT
RO
N dC
Output Run simultaneously with Main
Motor (004-021)
DC ON: PWM Output value = NVM
(0
-255) - Disch
arge (variable value)
/ NVM 774-031 = 1 o’clock output
value = 0 / NVM 774-031 = 2
o’clock output value = 96.
NVM 774-033 / NVM 774-031 = 3
o’cloc
k out
put value = 130 NVM
774-029
Processor
009-070 CHARGE COROTRON
WIRE
O
utput Run Simultaneously with Drum
Motor (004-021)
Processor
009-074 SAW COROTRON dC Output ON: 3 KV - Discharge. (can be
changed in NVM
771-034)
Processor
009-076 DEVE BIAS dC Output ON: PWM Output Value - 573
fixed - Apply
Processor
009-077 DEVE BIAS AC COLOR Output ON: PWM Output Value - 165
fixed - Apply
Cannot be run with Deve Bias - AC
B/W
(009-079)
Processor
009-079 DEVE BIAS AC BLACK Output ON: PWM Output Value - 165
Cannot be run with Deve Bias - AC
Color (009-
077)
Pr
ocessor
Table 2 Output Component Control Codes
I
D Descri
ption In_Out Smart Help
Module_I
D
