iNFiNiT! Family Operation Manual
Revision
7-1
Formattin
& Editin
Table 7-1: Tab Setup - Field Characteristic Commands
.(<6752.(6 &200$1'
A
All data aligns vertically on the first decimal point
B
All data aligns vertically on the first comma
C
Center Justify - Centers all text in the tab field
L
Left Justify - Aligns all text to left edge of tab field
N
No Justify - Turns off text alignment in the tab field
R
Right Justify - Aligns all text to right edge of tab field
SPACE BAR
Toggles through available justifications
F
Col/Font - Selecting F allows the user to predetermine fonts
or colors in the tab field. Additional fonts and colors can be
selected in Message Compose Mode
Color Keys
Press to select a character color for the tab field
Font Keys
ALT Font
Keys
Press to select a font for the tab field
COLOR
FONT
Sets tab field to current color and font of the character the
cursor is on
I
Initializes (clears settings) tab field
H
Allows you to assign a name to each tab field
J
Renumbers all fields in order (0, 1, 2, 3...) from left to right,
top to bottom
O
Renumbers the current tab field number to a newly entered
value
K
Forces upper case typing in this field
U
Numeric
- Compensates for the different widths of numbers
by aligning them vertically within tab fields in a uniformly
spaced fashion
T
Auto Erase - Clears field for new data when updating. When
set, all data in the tab field is erased when the first new char-
acter is typed on re-entry into the tab field.
X
External Input - Enables tab field update by Intelligent Inter-
face
Z
Turns off external update for all tab fields
M
Mark On/Off
- If On, displays tab field markers when you
exit from Tab Setup. This must be set for each frame buffer.
Table 7-1: Tab Setup - Field Characteristic Commands
.(< 6752. (6 &200$1'
