Chyron infinit! series - 14.8.3 iNFiNiT! Input Switching Single User, Three Frame Buffers

CHYRON Corporation
Buffers & Channels 14-34 Revision D
 L1)L1L7,QSXW6ZLWFKLQJ
6LQJOH8VHU7KUHH)UDPH%XIIHUV
A three buffer system (Figure 14-8) is configured as a
three 3:1 (3 input:1output) switchers. The input to each
of the switchers (CHANNEL A, CHANNEL B or PRE-
VIEW) can be FB-A, FB-B, FB-C or black.
Figure 14-8. Input Switching - Three Frame Buffers
3:1
Buffer 1
Buffer 2
A
Buffer 3
3:1
Buffer 1
Buffer 2
B
Buffer 3
3:1
Buffer 1
Buffer 2
PREVIEW
Buffer 3
