Chyron infinit! series - 7.4.3.2 Numeric Fields (U); 7.4.3.3 Assigning Color or Font (Color and Font Keys)

iNFiNiT! Family Operation Manual
Revision D 7-21 Formatting & Editing
 1XPHULF)LHOGV8
Numeric On is used primarily with right justified text,
although it works with all styles of justification. All dig-
its entered in a numeric field align themselves with digits
in other numeric fields in columns of equal width.
To activate, press
U or select the Numeric icon.
Figure 7-4. Numeric Fields Off/On
When Numeric is set to On, Numeric appears in the Jus-
tify
field. For example, a right justified numeric field is
designated as follows:
Figure 7-5. Justify: Field
 $VVLJQLQJ&RORURU)RQW 
&RORUDQG)RQW.H\V
To set color and/or font for a tab field:
• Place the cursor on a tab field, then press a
Color
Key
and/or a Font or ALT Font Key.
OR...
5 5 5 5 5 5 5 5
1 1 1 1
1 1 1 1
2 2 2 2
2 2 2 2
Numeric Fields Off
Numeric Fields On
Justify: Right Justify - Numeric
