Multiple Effects 17-44 Revision D
 0XOWLSO H(IIHFWV6 HTXHQFH( [HFXWLRQ
8VLQJD)X QFWLRQ.H\
A series of prerecorded Multiple Effects messages can be
loaded and executed by using a Function Key. This
allows you to execute an entire sequence using one key-
stroke. Each Multiple Effects message must be triggered
by its own Trigger Fx command. See Section 12 for
information on programming Function Keys.
 6LPXOWDQHRXV5ROO&UDZO7XWRULDO
The following tutorial outlines the general procedure for
executing a simultaneous Roll and Crawl:
[ ] 1. Enter the message ID number of a Roll
message into the
Mesg field for one of the
frame buffers in the Multiple Effects main
menu. Select
Roll in the Type field. Enter
Start and End points.
[ ] 2. Enter the message ID number of a Crawl
message into the
Mesg field for another frame
buffer in the Multiple Effects main menu.
Select
Crwl in the Type field. Enter Start and
End points.
[ ] 3. Execute as described in §17.10.
ALT DO
Triggers a loaded or paused Transform script. This
command can be used to continue execution of a
Transform script without disturbing other frame buffers.
During a pause, a new Multiple Effects message can
be loaded or created.
ALT RCD
Preserves old message description entered in the
Name: field when recording over a file that already
exists.
