Multiple Effects 17-6 Revision D
CNTL X: Loads and executes current Multiple
Effects settings (§17.10).
CNTL Q: Exits the Multiple Effects main menu.
Settings are saved until exiting Message
Compose, or rebooting or turning off the system.
 0XOWLSOH(IIHFWV:LQGRZ
The Multiple Effects window (Figure 17-3), contains the
same features available through Advanced Read FX
(Section 15) and Mix Effects (Section 16). Read and Mix
Effects execute transitions from one stored image to
another using one or more frame buffers. In the Multiple
Effects window, more than one Read and/or Mix Effect
can be set up and triggered simultaneously.
Figure 17-3. Multiple Effects Window
Several parameters can be set in the Multiple Effects
window.
•
Buf (Buffer selection): Frame Buffers 1, 2, 3, Mix
• Type (Effect Type): Wipe, Push, Revl, Hide, Dislv,
Cut, Roll, Crwl, Fade, Wipe1, Push1, DDR, CMF
Execute
X
Quit
Q
Buf EndRev MesgEaseType LenStartEffect
1
2
3
Mix
Push
Revl
Wipe
Fade
A
B
A
N/A
148
157
0
205
900
901
None
None
None
None
Off
Off
Off
Off
0
69
0
18
148
226
0
223
Multiple Effects
