iNFiNiT! Family Operation Manual
Revision D 2-35 Installation
/XPD&KURPD7LPLQJ
[ ] 1. Attach the 601 CH1 OUT or CH 2 OUT connector
to the Magni 125DA (or equivalent) via a twisted-
pair cable.
[ ] 2. Attach a component waveform monitor to the
YgCrCb
outputs of the Magni.
[ ] 3. Type a WHITE vertical bar on the monitor, as far to
the left as possible.
[ ] 4. Using the waveform monitor, adjust
SW1
until the
luminance (Y) pulse is as far to the left as possible,
without losing any of it.
[ ] 5. Change the color of the bar to RED. Adjust
SW2
until the
CrCb
values are coincident with the
luminance (Y) value.
.H\7LPLQJ$GMXVW
[ ] 1. Connect the 601 output from the iNFiNiT! to the
MAIN input of the Magni.
[ ] 2. Connect the iNFiNiT! 601 KEY output to the AUX
input of the Magni.
[ ] 3. Attach the
YgCrCb
outputs from the Magni to a
component waveform monitor.
[ ] 4. Type a WHITE vertical bar on the iNFiNiT! screen.
[ ] 5. Look at the main Magni channel. Mark the position
of the bar on the waveform monitor.
[ ] 6. Switch the Magni to the AUX channel. On the 601
board, adjust
SW6
until the key output lines up
with the video output.
This concludes the iNFiNiT! 601 video adjustments.
0$;,1(&&,5'LJLWDO9LGHR
2SWLRQ$GMXVWPHQWV
NOTE
The MAXINE! Digital Video Option
provides Serial 601 inputs/outputs.
