CHYRON Corporation
Installation 2-12 Revision D
 9 LGH R&RQQHFWLRQVL1)L1L7
The two sets of BNC connectors on the iNFiNiT! rear panel
marked CHANNEL 1 and CHANNEL 2 (Figure 2-7) are com-
pletely independent. Except where noted, the following
descriptions apply to both channels.
EXT SCSI
The Small Computer System Interface (SCSI) is the I/O
port for the internal hard drive. A SCSI Terminator, or
external disk storage unit(s) attach to this connector.
If
no external drive units are connected, the sup-
plied SCSI terminator must be installed here for
proper hard disk operation!
GPI
General Purpose Interface. Allows you to use remote
switches to activate Function Keys
F1
through
F8
.
ETHERNET
Network connection, for use with Network Utilities
option.
Table 2-2: iNFiNiT! Video Connections
&RQQHFWRU )XQFWLRQ
CHYRON
VIDEO
Output consists of iNFiNiT! text, graphics, effects, and/or
backgrounds. Does not include Safe Title Box, cursor, or tab
fields. (1.0v p-p)
COLOR
EDIT
Same as CHYRON VIDEO, plus displays Safe Title Box,
cursor, and tab fields. (1.0v p-p)
SYNC
If component output (RGB) is used, this jack supplies com-
posite sync to the SYNC IN jack of your equipment.
(4.0v p-p NTSC; 2.0v p-p PAL)
BLUE
If RGB/YUV equipped, supplies the blue or U component
from the RGB/YUV board. (0.7v p-p)
GREEN
If RGB/YUV equipped, supplies green or Y component, and
sync (if desired), from the RGB/YUV board.
(0.7v p-p)
Table 2-1: iNFiNiT! Rear Panel Connections
&RQQHFWRU )XQFWLRQ
